SGS Certified Waterproof Manhole Cover Foundry

Name: SGS Certified Waterproof Manhole Cover Foundry
Brand: china-castingforging.com
SKU: 687291522
Availability: InStock
Rating: 5 (144 reviews)

Price:	US $ 1-200/Set
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Paypal,Western Union

Contact Supplier

SYI Industrial Co., Ltd.

Showroom Product Company Profile

Prod Model:	LD/MD/HD
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product:	En124 D400 Double Seal Manhole Cover
Surface:	Bitumen/Epoxy Painting
Serivce:	OEM/ODM Available
Drawing Format:	Proe, Solid Work, Autocad etc
Certifiate:	Bsi Kite Mark& TUV ISO 9001&BV&SGS
Inspection:	Professional Lab
Loading Test:	as Per En124
Others:	Owning Experienced Designing Team
Export Markets:	Global
Material:	Ductile Iron

Product Description

Welcome to SYI Group

EN124 D400 Double Seal Manhole Cover
About Our EN124 D400 Double Seal Manhole Cover:

Ductile Iron
Hinge Type (available)
Single seal / Double seal (available)
Lock(available)
Closed key hole (available)
Recessed type (available)
Two lifting Key holes (available)
Double triangular (available)
Cut-corner Design (available)

EN124 D400 Double Seal Manhole Cover
About SYI Group Information:

About SYI Foundry
SYI Foundry has been involving in casting business for more than 20 years. Based on good quality, competitive price, on-time delivery, we've got great reputation all over the world. Not only do we have advanced equipments, but also own a very strong engineering team. Some of our engineers have been working in casting fields for over 30 years.

All castings shall be smooth and free from sand holes, blow holes, distortion or any other defects.

With annual production capacity of 35, 000 tons, our major equipments include 2 sets of automatic moulding lines, 4 sets of 5-ton cupola, 2 sets of load test machines, 1 epoxy coating machine, 3 sets of core-shooting machines, 3 sets of shot blasting machines, 2 sets of water pressure machines, 2 machining workshops and all necessary chemical and physical test facilities.

GUARANTEE: SYI Foundry will replace any Heavy Duty covers/gratings, that has been properly installed and broken in normal use, free of charge after receipt of the broken casting.

Production Facility
Besides traditional hand moulding, we also use Automatic Moulding Lines to manufacture manhole covers for better surface condition and dimension accuracy.

Quality Control
Quality Control Department

Raw Material Inspection
Raw Material inspection including chemical
Components analysis, tensile strength test and etc.
Quality Control Groups
Dimensions Test
Manufacture process Inspection
Process Inspection including sand cleaning, assembling, packing and coating
Final Inspection including delivery marks and etc.
Particular Tests for different products, such as Load Test, Hydro Test and etc.
Laboratory
Chemical Components
Microstructure Test
Tensile Strength
Our EN124 D400 Double Seal Manhole Cover:

EN124 D400 Double Seal Manhole Cover
Contact Us:
If you have any specific inquiry about EN124 D400 Double Seal Manhole Cover, please contact us via the following ways:
1. Tel: 0086 351 2027764
2. Fax: 0086 351 4040962

Product Code	Specification	Clear Opening (MM)	Hight	Lockup Device		Muffler Cushin	Lockset	Rate Of Load
Product Code	(MM)	Clear Opening (MM)	(MM)	Bolt	Hinge	Muffler Cushin	Lockset	(KN)
SCA318D	318*318	290*290	100	√		√	√	400
SCA336D	336*336	300*300	100	√		√	√	400
SCA425D	425*425	390*390	100	√		√	√	400
SCA484D	484*484	450*450	100	√		√	√	400
SCA625D	625*625	490*490	100	√		√	√	400
SCA725D	725*725	700*700	100	√		√	√	400

About SYI Group

Specialist in Municipal, Drainage & Machinery Products & Services

SYI Group Companies have served the society for over 20 years with best Municipal, Drainage and Machinery products.

* SYI Foundry (Shanxi Yuansheng Casting & Forging Industrial Co., Ltd. ) --- manufactures Manhole Covers, Gully Gratings, Surface Boxes, Tree Gratings, Bollards, Garden Benches, Cast Lamp Posts & Bases and all types of SYI/OEM municipal products and outdoor furnitures.

* SYI Pipeline Corporation --- manufactures a full range of Pipeline products and accessories like Pipes, Fittings, Universal Couplings, Flanged Adaptors, Quick Adaptors, Dismantling Joints, Clamps, Valves, and etc.

* SYI Industrial Casting Division (Shanxi Yuansheng Industrial Co., Ltd. ) --- manufactures all kinds of Investment Castings / Precision Castings, Lost-Wax Castings, Resin Sand Casting, Lost Foam Castings and more.

* SYI Forging Factory (Shanxi Yuansheng Casting & Forging Industrial Co., Ltd. ) --- manufactures Flanges, Forged Rings, Forged Fittings, Lifting Anchors, Drop Forgings, Cold Forgings and other Free Forging and Die Forging products.

* SYI Aluminum Division --- manufactures Aluminum Sand Castings, Permanent Mould, Aluminum Die Castings, Aluminum Extrusions and all types of aluminum products.

Since the second half of 20th century, SYI has been an OEM manufacturer of machined & un-machined castings and forgings in a variety of industries. Today, we manufacture over 1, 000 products - everything from single flange to customized street lamps. SYI are continuing to refine our role as a technical expert, quality leader and fast reactor.

At Shanxi base, we have over 500, 000 square meters of workshop, warehousing and production facilities. We have 6 automatic moulding machine lines, CAD machining center, professional laboratory, in-house pattern & tooling shops and most important-a group of highly experienced and technically qualified staff.

SYI regards quality as an essential and integral part of our business success. Until now, we are ISO9001: 2008 TUV certified, BSI Kitemarked, SGS certified, UL listed, FM certified and NF certified. Manufacturing "SYI" Brand products has evolved as a mark of quality!

SYI also has the capacity to assist the customer from initial design, engineering to final sample and production.

Our aim is to provide all of our customers with VALUE of the products in stead of only low prices.
