| Prod Model: |
Single bimetallic screw barrel |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
| Type: |
Pipe Extruder |
| Screw: |
Twin-Screw |
| Automation: |
Automatic |
| Computerized: |
Computerized |
| Plastic Processed: |
WPC |
Product Description
Bimetallic screw barrel, Tungsten Carbide Screw Barrel, bimetal screw barrel, plastic machinery screw barrel, extrusion screw barrel, twin parallel screw barrel
Specification:
Screw diameter: 15mm-300mm
Maximal length: 8000mm
Barrel inner diameter: 15-300mm
Maximal length: 4000mm
Different bimetallic alloys are available for different raw materials.
1. Tungsten carbide screw and barrel
2. Wear resisting
3. Low power
4. Low noise level
5. High quality material
Application: Injection molding machine, extrusion
Base Materials:
(1)38CrMoAlA(JIS SACM645)
(2)42CrMo(AISI 4140)
(3)9Cr18MOV
Technics:
Heat treatment
High-frequency quenching
Nitriding treatment
Hard-chrome electroplating
Bimetallic alloy welding
Bimetallic alloy centrifugal casting
Technical parameter:
Nitrided layer depth: 0.5-0.8mm
Nitrided hardness: 900-1000HV
Nitrided brittleness: Less than grade 1
Surface roughness: Ra0.4
Linearity of screw: 0.015mm
Hard-chrome plating hardness after nitriding: ≥ 950HV
Chrome-plating layer depth: 0.025-0.085mm
Bimetallic layer depth: 3mm
Warranty and service: 1 year
Experienced manufacturer, we will be the best choice.
|
Base Materials: |
1)38CrMoAlA(SACM 645)
2)42CrMo(AISI 4140)
3)Cr12MoV(SKD11)
4)4Cr5MoSiV1(SKD61)
5)9Cr18MoV
6)40Cr |
|
Bimetallic Alloy Materials: |
1)Fe-based alloy
2)Ni-based alloy
3)Co-based alloy
4)Tungsten carbide |
Bimetallic alloy level:
|
Alloy powder including 40% Tungsten Carbide
Alloy powder including 25% Tungsten Carbide
Alloy powder including 9.5% Tungsten Carbide |
|
Processing Technology: |
Heat treatment
High-frequency quenching
Nitriding treatment
Hard-chrome electroplating
Bimetallic alloy welding |
Technical Parameter:
|
Nitrided layer depth:0.50-0.80mm
Nitrided hardness: 950-1100HV
Nitrided brittleness: Less than 2 level
Surface roughness: Ra 0.4 μm
Linearity of screw: 0.015mm/m
Hard-chrome plating hardness after nitriding: ≥950HV
Chrome-plating layer depth: 0.025~0.10mm
Bimetallic layer depth: 3-5 mm
Bimetallic hardness: HRC60-70 |
|
Suitable Plastic Material: |
PP, PE, HDPE, LDPE,LLDPE etc. |
Our products advantages: |
1)High productivity 2)Good plasticizing effect
3)Low energy consumption 4)Wear resistant&Corrosion resistant
5)Long using life 6)Fast production&On time delivery
7)Best customer service! |
