| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe |
| Type: |
General Rubber Machinery |
| Type Of General Rubber Machinery: |
Material Processing Machine |
| Type Of Tire Machinery: |
Rubber Regeneration Machinery |
| Application: |
Rubber Extruder |
| Base Material: |
38crmoala |
| Nitrided Hardness: |
900-1000hv (HRC 55-65) |
| Nitrided Layer Depth: |
0.5-0.8mm |
| Nitrided Brittleness: |
Less Than Grade 1 |
| Surface Roughness: |
Ra 0.4 |
| Linearity Of Screw: |
0.015 Mm |
Product Description
Single screw barrel for rubber machinery screw cylinder
Specification:
Screw Diameter for Cold Feeding Screw and Barrel: Φ 40mm-Φ 300mm
Screw Diameter for Hot Feeding Screw and Barrel: Φ 30mm-Φ 250mm
Screw Diameter for Pin Rubber Screw and Barrel: Φ 50mm-Φ 250mm
L/D Ratio: 4-18
Technical information:
Base materials:
1)38CrMoAlA (JIS SACM645)
2)42CrMo (AISI 4140)
3)4Cr5MoSi V1 (JIS SKD-61)
4)DC53 (JIS G4404)
5)Cr12MOV (SKD11)
6)9Cr18MOV
Bimetallic alloy materials:
1)Ni-based alloy/Deloro alloy
2)Fe-based alloy
3)Co-based alloy
4)NiCo-based alloy
5)Tungsten carbide/Wolfram carbide
Processing technics:
Heat treatment
High-frequency quenching
Nitriding treatment
Bimetallic alloy welding
Bimetallic alloy centrifugal casting
Hard-chrome electroplating
Technical parameters:
Nitriding layer depth: 0.5-0.8mm
Nitrided Hardness: 900-1000HV (HRC 55-65)
Nitrided brittleness: Less than grade 1
Surface roughness: Ra 0.4
Linearity of screw: 0.015mm
Bimetallic layer depth: 3 mm
Bimetallic layer hardness: HRC 55-70
Hard-chrome plating hardness after nitriding: ≥ 950HV
Chrome-plating layer depth: 0.03-0.1mm
Terms and Conditions:
Means of transport: Ocean, Air, Express
Production time: About 20-30 days after we receive the advanced payment
Production Process:
Receiving orders - Designing & Drawing confirmation - Blanking Thermal refining - Heat treatment - Rough Turning - Polishing - Drilling for barrel - Semi Finishing Machining - Bimetallic welding - Centrifugal casting for barrel - Polishing - Nitriding treatment(120 hours) or High frequency quenching - Hard-chrome plating - O. D. Grinding - Honing for barrel - Alignment - Polishing - Inspecting - Packing & Shipping
We are most professional screw barrem manufacturer from China. Welcome to contact us, Tracy will reply you timely!
|
Means of transport |
Ocean, Air, Express |
|
Production time |
About 20-30 days after we receive the advanced payment |
|
JL SCREW's advantage: |
|
First-class designing and researching team; |
|
High quality and durable products of screw barrel; |
|
Most professional sales who can serve for you timely; |
|
Best customer service especially after-sale service; |
|
Powerful company's strength support long-term cooperation. |
Zhoushan Jinli Screw Industry Co., Ltd was established in the year of 1998, we are a professional manufacturer of designing, researching and manufacturing all kinds of screws, barrels and other accessories for plastic and rubber machinery.
Our company is located in Zhoushan city, it covers an area of 12000sqm and has over 100 employees. We are well equipped with a variety of advanced machines, experienced R&D team, strict quality control system and perfect after-sale service. These conditions are ensuring us best quality and creating more and more long-term customers.
In order to keep high quality, we built quality control system strictly follow ISO9001: 2008 international Quality System and kept effective operating. As a result of our high quality products and outstanding customer services, we have gained a global sales network reaching Middle East, Southeast Asia, Eastern Europe, Africa, South America etc.
With the JinLi spirit of "based on sincerity, build a win-win situation", in the past twenty years, we developed together with customers. We believe our unremitting efforts will help us win greater markets and play a bigger role in this field in the future.
