| Price: | US $ 1-2.2Kg |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Paypal,Western Union |
| Prod Model: | OEM |
|---|---|
| Markets: | North America,South America,Eastern Europe,Oceania,Mid East,Eastern Asia,Western Europe |
| Report: | SGS |
| Casting Method: | Thermal Gravity Casting |
| Material: | Cast Steel |
| Surface Preparation: | Sand Blast |
| Plain Carbon Cast Steel |
| Standard-Spec.No.& Grade | Chemical Composition≤% | Mechanical Properties≥ | NOTE:(1)S,P≤0.04% (2)C,Mn%can also be agreed upon by manufacturer and purchaser. (3)Heat Treat:Normalize(N)+Temper(T) or Quench(Q)+T,selected by Foundry | |||||||
| GB China | JIS Japan | ASTM U.S.A. | C | Si | Mn | T.S. σb N/mm2 | Y.S. σs N/mm2 | EL δ% | R.A. ψ% | |
| ZG200-400 | SC420 | A27 60-30 | 0.2 | 0.5 | 0.8 | 400 | 200 | 25 | 40 | |
| ZG230-450 | SC450 | 65-35 | 0.3 | 0.9 | 450 | 230 | 22 | 32 | ||
| ZG270-500 | SC480 | 70-40 | 0.4 | 500 | 270 | 18 | 25 | |||
| ZG340-640 | SCC3B | A148 80-50 | 0.6 | 0.6 | 640 | 240 | 10 | 18 | ||
| High Alloy Cast Steel |
| Standard-Spec.No | Chemical Composition% | Mechanical Properties≥ | |||||||||
| GB China | JIS Japan | ASTM(AISI) U.S.A. | C | Si | Mn | Cr | Ni | Others | T.S. σb N/mm2 | Y.S. σs N/mm2 | EL σ% |
| ZG1Cr13 | SCSI | CA-15(410) | ≤0.15 | ≤1.50 | ≤1.00 | 11.5-14.0 | ≤1.00 | Mo≤0.05 | 620 | 450 | 16 |
| ZG0Cr18Ni9 | SCS13 | CF8(304) | ≤0.08 | ≤2.00 | ≤1.50 | 18.0-21.0 | 8.0-11.0 | 440 | 185 | 30 | |
| ZG1Cr18Ni9 | SCS12 | CF20(302) | ≤0.20 | ≤2.00 | ≤1.50 | 18.0-21.0 | 8.0-11.0 | 480 | 205 | 28 | |
| ZG0Cr18Ni12Mo2Ti | SUS316 | CF-8M(316) | ≤0.08 | ≤1.50 | ≤1.50 | 18.0-21.0 | 9.0-12.0 | Mo 2.0-3.0 Ti0.7 | 490 | 216 | 30 |
| ZG0Cr17Ni4Cu4Nb | SUS630 | CB-7Cu 17-4PH | ≤0.07 | ≤1.00 | ≤1.00 | 15.5-17.0 | 3.0-5.0 | Cu2.3-3.0 Nb0.14-0.45 | 980 | 785 | 5 |
| ZGMN13-3 | SCMnH2 | A128 B-1 | 0.90-1.30 | 0.30-0.80 | 11.0-14.0 | S≤0.05, P≤0.08 | 686 | 35 | |||
| ZG3Cr18Ni25Si2 | SCH19 | A297 HN | 0.20-0.50 | ≤2.00 | ≤2.00 | 19.0-23.0 | 23.0-27.0 | Mo≤0.50 | 435 | 230 | 8 |
| ZG4Cr25Ni20Si2 | SCH22 | A351 HK-40 | 0.35-0.45 | ≤1.75 | ≤1.50 | 23.0-27.0 | 19.0-22.0 | 450 | 240 | 10 | |
| Note:S,P≤0.04% except 13%Mn Steel(ZGM13-3) |
| Copper-base Cast Alloy |
| Standard-Spec.No. | Chemical Composition% | Mechanical Properties≥ | |||||||||
| GB China | JIS Japan | ASTM U.S.A | Sn | Zn | Pb | Si | Cu | T.S.σb N/mm2 | Y.S. σ% | EL HBW | Hard ness |
| ZCuSn5Pb5Zn5 | BC6 | C83600 | 4.0-6.0 | 4.0-6.0 | 4.0-6.0 | Balance | 200 | 90 | 13 | 60 | |
| ZCuSn10Zn2 | BC3 | C90500 | 9.0-11.0 | 1.0-3.0 | 240 | 120 | 12 | 70 | |||
| ZCuZn16Si4 | SZBC3 | C87800 | Balance | 2.5-4.5 | 79.5-81.0 | 390 | 20 | 100 | |||
| ZCuZn40Pb2 | C85700 | 0.5-2.5 | 58.0-63.0 | 220 | 120 | 15 | 80 | ||||
