Stainless Steel Wn RF Flanges (Weld Neck)
| Price: |
US $ 10-100/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
| Prod Model: |
1/2-72" WN RF Flanges |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Types:T Weld Neck, Socket Weld, Threaded: |
Technics:T Forged |
| Material: |
Stainless Steel |
| Manufacturing Way: |
Forging |
| Standard: |
GOST |
| Type: |
Welding Flange |
Product Description
Standards: ANSI, BS, DIN, JIS and MSS etc.
Materials: Carbon steel, Stainless steel and Alloy steel etc.
Size: 1/2" ~ 64"(DN15 mm ~ 1600 mm)
Type: Slip-On, Welding Neck, Blind, Socket Welding, Threaded, Lap Joint and Plate etc.
Pressure Ratings: Class 150, 300, 600, 900, 1500 and 2500
Pressure Ratings: PN 6, PN 10, PN16, PN25, PN40 and PN64
Pressure Ratings: JIS 5K, 10K, 16K and 20K
|
Flange Standard |
Flange Size |
Flange Pressure |
Flange Type |
|
ANSI B16.5 |
1/2''-24'' |
Class150 Class300 |
Blind Plate Slip on Welding Neck |
|
ASME B16.5 |
Class600 Class900 |
Socket weling Threaded RTJ(tring type joint ) |
|
ASA B16.5 |
Class1500 Class2500 |
Facing: FF (flat face) RF (raised face) |
|
ANSI B16.47 (A) |
1/2''-60'' |
Class150,300 |
Slip on Welding neck RTJ(ring type joint) |
|
Class400,600,900 |
Facing: FF (flat face) RF (raised face) |
|
ANSI B16.5 (B) |
26''-60'' |
Class75,150,300 |
Slip on Welding neck RTJ(ring type joint) |
|
Facing: FF (flat face) RF (raised face) |
|
ANSI B16.36 |
1"-24" |
Class300,400,600 |
Slip on Welding neck Threaded RTJ |
|
Class900,1500,2500 |
Facing: FF (flat face) RF (raised face) |
|
EN1092-1 Type01 |
DN10-DN2000 |
pn6 pn10 pn16 pn25 pn40 |
Plate flange |
|
EN1092-1 Type05 |
DN10-DN3000 |
pn6 pn10 pn16 pn25 pn40 |
Blind flange |
|
EN1092-1 Type11 |
DN15-DN3000 |
pn6 pn10 pn16 pn25 pn40 |
Welding neck flange |
|
EN1092-1 Type13 |
DN10-DN150 |
pn6 pn10 pn16 pn25 pn40 |
Threaded flange |
|
EN1092-1 Type02 |
DN15-DN1000 |
pn6 pn10 pn16 |
Loose flange |
|
GOST 12820-80 |
DN15-DN2000 |
pn0.6MPa 1.0MPa 1.6MPa |
Plate flange |
|
pn2.5MPa 4.0MPa 6.4MPa |
FF(flate face) RF(raised face) |
|
GOST 12821-80 |
DN15-DN2000 |
pn0.6MPa 1.0MPa 1.6MPa |
Welding neck flange |
|
pn2.5MPa 4.0MPa 6.4MPa |
FF(flate face) RF(raised face) |
|
GOST 12836 |
DN15-DN2000 |
pn0.6MPa 1.0MPa 1.6MPa |
Blind flange |
|
pn2.5MPa 4.0MPa |
FF(flate face) RF(raised face) |
Tianjin Golden Hugeline Co., Ltd., located in Tianjin city, is one of the biggest steel groups. Golden Hugeline Group are specialized in producing and exporting all kinds of steel pipe and fittings, flanges, valves in China. Our group is established in 1995 and We have over 15 years' Experience in steel market.
Our group have four branches. The factories of steel pipe and pipe fitting are located in Hebei Province, one flange factory is located in Shanxi Province, and the last one is our sea shipping company in Tianjin. Our main products are pipe fittings, pipes, flanges, valves and so on. We can manufacture according to ANSI/ASTM, JIS, DIN, API, GOST and non-standard. The sizes are 1/2" up to 72" for pipe fittings, 1/2" up to 32" for flanges, 1/2" up to 24" for pipes, 1/2"up to 24" for valves.
Our products have been widely used in many projects. Also we are a good supplier of SGS and have passed ISO, API, TUV, EC and so on. Till now, we have exported to Vietnam, British, Sweden, Japanese, Korea, India, Brazil, Germany, Africa and Middle East counties. We have good reputation from our customers and have long term cooperation with them.
We sincerely hope to cooperate with new and old friends and warmly welcome you to visit our factory.
SKYPE: Huweiyan001 whats APP and wechat: 0086-13752320560
