| Prod Model: |
casting bogie for freight wagon |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Method: |
Casting |
| Used For: |
Bogie |
| The Material: |
Steel |
| Type Of: |
Freight Wagon |
| Application: |
Freight Wagon |
| Material: |
Steel |
| Casting Tolerance: |
+/-2mm |
| Certification: |
Tb |
Product Description
Our Certifications and Features are:
1. Got the American "AAR" Certification;
2. Got the Russian Certification;
3. Got the Ukrainen Certification;
4. Using the German "V" modeling technology;
Side frame - one of the main structural elements of the bogie framework of the model 18-100. It is manufactured by casting, with additional machining and riveting of wear-resistant plates. Side frame, drawing No. 100.00.002-4SB, represents a major piece of a freight wagon bogie, which transmits the load on the axle through the axle box. Cast alloy steels 20GFL and 20GL.
Bolster drawing No. 100.00.001-6 serves as a bridge between the two side frames in the construction of a freight wagon bogie. To ensure reliability and durability the bolster is casted from steel 20GFL or 20GL. One of the main frame details of a bogies framework Model No. 18-100. Set lifetime of a bogie frame before a bolster discarding is 30 years. The designated lifetime up to the first depot repair is 2 years, before the first overhaul is 8 years. Established time to failure is at least 2 years.
Overall dimension:
Side frame: 2.41m*680cm*56cm weight: 400kg
Bolster: 2.61m*39.5cm*47cm weight: 525kg.
Tedrail can supply most of railway products, such as Bogie parts, Wagon parts, Coach parts, Locomotive parts based on customers' requirements. We have a professional technical and quality assurance team, well understanding of international railway products standard or specification, expert in design, manufacture, and inspection for railway products. With our experienced and educated business team, Cooperated with Chinese railway industrial university, Tedrail has got most valuable technical support and knowledge base.
Tedrail is focused on the complete solution of railway industry, and interested in sharing experience and cooperation with all parties in the world.
Our Team
We have a strong technical team, lots of them have been engaged in the production line for many years, with a more profound experience about production and processing of products.
Our team comprises:
Management Team
Senior Engineer
Engineer
QA Team
Workshop staff
QA Team
We have a professional technical and quality assurance team, well understanding of international railway products standard or specification, expert in design, manufacture, and inspection for railway products. We will make sure give customers best design and most reliable and safe products. With our experienced and educated business team, Tedrail give customers easiest and convenient business service.
Our railway industrial products are tested:
1. Chemical Analysis
2. Metallographic
3. Mechanical Analysis
4. Ultrasonic Testing
5. Magnetic Testing
6. Impact Testing
7. Hardness Testing
8. Surface Quality
Customer Satisfaction
For attaining customers' satisfaction, we manufacture and supply superior quality railway products that are cost efficient and highly durable. Our railway products are manufactured by using superior quality raw materials and checked by our quality analysts at every level of production process. Our range of products is widely acknowledged by our customers because of its quality and effectiveness.
Why Us?
We are one of the most promising organizations who have achieved a leading position in this domain due to the following factors:
Rigorous quality control measures
State-of-the-art infrastructure
Ethical business policies
Experienced professionals
Wide distribution network
Team of skilled personnel
On time delivery
