| Prod Model: |
200-550 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Voltage: |
220V/380V/440V |
| Raw Material: |
Steel/Aluminium/Other Metal |
| Fuel: |
Gas/Oil/Diesel |
| Dimension: |
2700*1900*2300mm |
| Color: |
Optional |
| Working Type: |
Hot Rolling/Cold Rolling |
| Delivery Time: |
Two Months |
| Secondary Or Not: |
New/Used |
| Alloy Or Not: |
Non-Alloy |
| Delivery Port: |
Qingdao |
| Forging Forming Method: |
Mold Forging |
Product Description
Brief Introduction of steel-making and continuous casting system
Our company is professional manufacturer of electric arc furnace, medium- frequency furnace steelmaking, secondary refining and continuous casting. We are also manufacturer of steel rolling production line including designing, manufacturing, installation, debugging and trial production. Meantime, our company can also undertake engineering consultation, engineering designing and engineer project contracting (Turnkey project).
Steel-making project
Our company can manufacture the electric arc furnaces (capacity: 0.5t-100t) which are matched for steel making - continuous casting - rolling mill. The capacity of medium-frequency furnace is 2~30t. And our refining furnaces are including FL, VOD, AOD, VD. Furthermore, kinds of submerged arc furnace are also in the scope of our supply.
Continuous casting project
Continuous casting machine is the main product of our company. Over the years, we have accumulated advanced production technology and experience in caster of square billet, round billet, rectangular billet, shaped section and steel slab.
Specification of casting billet:
Square billet: 60×60~1000×1000mm
Round billet:φ150~600mm
Rectangular billet: 120×350~220×480mm
Steel slab: 50×100mm 135~320×350~3000mm
| Sn. | Equipment | Unit | Qty | Unit weight(T) | Total weight(T) | Notes |
| I | Machinery parts |
|
|
|
|
|
| II | Φ 300 * 1 roughing mill parts | group | 1 |
|
| K11-K17 |
| 1 | Flywheel device(Φ 1680) | set | 1 | 6 | 6 |
|
| 2 | FZD80 herringbone gear reducer | stand | 1 | 7 | 7 |
|
| 3 | A = 300 triple type herringbone gear box | stand | 1 | 6 | 6 |
|
| 4 | Φ300Three roller bearing mill | stand | 1 | 10 | 10 |
|
| 5 | SWC315*1200 cardan shaft | piece | 3 | 0.72 | 2.16 | Including roll shaft joint |
| III | Tandem rolling (phi 250 * 2 tandem rolling) | group | 5 |
|
| K1-10,470-kw,5stand |
| 1 | ZD70 herringbone gear reducer | stand | 2 | 5 | 10 |
|
| 2 | A = 1400 two out of the shaft herringbone gear reducer | stand | 5 | 9 | 45 |
|
| 3 | Φ250 two roller bearing mill | stand | 10 | 5 | 50 |
|
| 4 | A = 250 double type herringbone gear box | stand | 10 | 2.2 | 22 |
|
| 5 | Automatic rev. Set of apparatus | stand | 2 | 3 | 6 |
|
| 6 | Card fault cut | stand | 2 | 1 | 2 |
|
| 7 | SWC250*850 cardan shaft | strip | 20 | 0.42 | 8.4 |
|
Regards
Sara
Anshan HongMing Metallurgical Machinery Co., Ltd.
Anshan Ying Yat Trade Co., Ltd.
Add.: No 116, Renmin Rd, Tiexi Dist., Anshan, Liaoning, China
Tel: 0086-412-8554528 8554538 8510377
M.B.: 0086-13700125807
Homepage: www.asyy888.com
Our company is a big exporter of various kinds of steel and iron products, metal mineral.
One of our strongest parts is steel rolling mill and machinery/ equipment & metal processing.
Here are our steel products:
Steel plate/sheet/coil, steel pipe/tube, steel bar/rod, section steel (angle bar, flat bar, channel bar, I-beam, H-beam, wire rod/steel wire and stainless steel products.
The steel rolling mill offered by us can produce steel bar/rod, section steel (angle bar, flat bar, channel bar, I-beam, H-beam, steel rails and wire rod/steel wire.
Meantime, we are also dealing with the forging, casting, machining, heat treatment, melted-zinc-bath, other equipment (motor, reducer, etc) and furnace (heating, annealing, tempering, melting and so on).
If you have any doubts, please contact us without hesitate and send us the full inquiry with the detailed specification, material, size & quantity.
