| Prod Model: |
TF-10T Hydraulic single arm decoiler machine |
Product Description
Hydraulic Decoiler Machine
Components
The decoiler consists of the coil car, decoiler, lead rail, and hydraulic system.
Used for the coil support and release, the decoiler body is welded by section steel and steel plate, single arm structure, motor reducer drive the decoiler, hydraulic drive wedge tight the inner wall of coil. The decoiler with the clamp arm and outer block set prevent the coil loose, reasonable structure, convenient operation, reduce the labor intensity, Photoelectric device monitor the position of coil loop, A high degree of automation
Applicable scope, technical parameters
Inner diameter of coil: φ 508mm
Outer diameter of coil: φ 1200mm
Width of coil: ≤ 1300mm
Load capacity: ≤ 10T
