| Prod Model: |
TF-20T Hydraulic Double cone top un-coiler |
Product Description
Used for the coil support and release and support the whole process. The uncoiler body is welded by section steel and steel plate for the double cabinet. Hydraulic double cone top structure, put the coil tightly against the double cone head, by hydraulic cylinder mobile activities end cone head, lock in top tight position Motor drive cone head spin, active feeding, can also be passive feeding, the system with force driving and damping also include the loading car.
Applicable scope, technical parameters
Inner diameter of coil: φ 508-610mm
Outer diameter of coil: φ 1800mm
Load capacity: ≤ 20T
Width of coil: ≤ 1500mm
Xinxiang Tianfeng Machinery Manufacture Co., Ltd a leading manufacturer for steel plate coiling machinery, cold-bending & rolling steel plate shaping machineries and automatic production lines. The products are mainly used in steel structure industry for producing C&Z type purlin, colored wall and floor protecting steel plate, thermal insulating plate and load-bearing plate of buildings, and other complementary thin wall cold-bending shaped seel plates, expressway railings, colorful decorating and protecting steel plates for high-grade steel structure residences.
