| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Thickest Of Rolling: |
10mm |
| Widest Of Rolling: |
600mm |
| Biggest Diameter Of Rolling: |
10000mm |
| Smallest Diameter Of Rolling: |
380mm |
| Diameter Of Roller: |
165mm |
| Speed Of Roller: |
63r/Min |
| Voltage: |
Three-Phase 380V |
| Electric Motor: |
11kw |
| Machine Size: |
3.1m*2.7m*1.4m |
| Machine Gross Weight: |
4t |
| Type: |
Metal Rolling&Drawing Machine |
Product Description
Main function
This machine is mainly used for rounding steel plate to form cylinder; It is an essential machine before welding the steel plate. It can be used for a light car, every variety of trucks, engineering car wheel, agriculture use car wheel, the felloe of no-inner tire circle process. And if assist with correspond of equipments; It may also used for processing other metals into circle.
Main features
This machine is three roller type structures, the upper roller is impetus revolving by speed reducer directly, and then the upper roller drives the two lower rollers to make the rotary motion through the chain wheel, the chain link, and providing the torque for the plate rolling system. The two lower rollers moving vertical through the elevator and make it possible to process different diameter of rims. The metal plate enters the processing under the upper roll, presses and rotary motion with the help of lower roller, enable the metal plate to pass through continuously curving, and the metal plate will have forever deformation, then get the final cylinder shape which will need.
|
Thickest of rolling |
10mm |
|
Widest of rolling |
600mm |
|
Biggest diameter of rolling |
1000mm |
|
Smallest diameter of rolling |
380mm |
|
Diameter of roller |
165mm |
|
Speed of roller |
63r/min |
|
Voltage |
Three-phase 380V |
|
Electric motor |
11KW(1450r/min) |
|
Machine size |
3.1M*2.7M*1.4M |
|
Machine gross weight |
4T |
Quanzhou taida car wheel equipment Co., Ltd is a professional machinery manufacturer established in 1995 with certification of ISO9001: 2000 quality management system, carrying out the 6s management all around, . It lies at the golden triangle area in south of fujian province --wuli bridge development area, shuitou town.
with long years elaborate management, our company has been grown from a small workshop into a comprehensive enterprise, integrating research, CAD mechanical design, manufacturing, testing, debugging, as well as after sale-service.
Main products: Automobile spoke spinning machine, vertical tubeless wheel rim programme controlled web-plate lathe, vertical automobile rim programme controlled lathe, multi-shaft spoke spot facer, internal/external plane vertical lathe for steel-ring assembly, dig slag machine, roll flattening machine, de-crowner, and roll forming machine etc. For our products, equipments and machines that used to processing wheel rim is our main products. In our factory, you can find all the machines which is needed in processing a wheel rim. with our machines, you can process the steel plate to an perfect wheel rim. As tne good quality and competive price, our products share a grate part of the market.
The top management of taida always pay a close attention to the change of domestic and foreign markets, adjusting the industrial structure timely, leading our technician\s to develope and research the latest products ceaselessly, which cover heavy, medium, and light industries of varieties and complete car wheel equipments.
Adhering to the principle of "professional and perfect, trustworthy and people oriented", taida plays his rule actively on the market of automotive wheel equipment. Meanwhile, with the principle of the pursuit of perfection, innovation.
We sincerely welcome old and new friends from over the world to visit us for exchange, here, we shall be always here for u, to make great progress and step forward for good development together.
