| Prod Model: |
U92 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Sales Area: |
Global |
| Packaging: |
Boxes or Pails |
| Body Material: |
42CrMo |
| Carbide Size: |
Yk05 |
| Carbide: |
19mm/22mm |
| Shank Size: |
35mm |
| Processing Technology: |
Forging |
| Certification: |
ISO9001: 2000 |
| Type: |
Mining Teeth |
| Application: |
Coal Mining and Rock Drilling |
Product Description
We are a professional productions base of series of rock drilling tools, mining tools, DTH Drill tools. Construction tools and excavating coal pick cutter tools, we can also produce other products according to the customers requirements. We sincerely welcome our friends of both home and abroad to come for business talks.
About products
1. Integral drill steels (Integral Drill Rods)
Shank H22x108mm, H19x108mm, standard hex. Bit diameters include 20-42mm.
2. Tapered drilling tools (Tapered Drill Steel)
Including:
Shank H22x 108mm, (6, 7, 11, 12 degree taper) taper rods in most lengths.
A comprehensive range of button bits, cross bits and chisel bits with (6, 7, 11, 12 degree taper).
Bit diameter: 28mm-57mm.
3. Extension drilling tools
Button bit, face design: Flat face, Drop centre, Normal and Retrac body.
Tungsten carbide (Buttons): Spherical, Ballistic and Conical. (Threaded R32, R38, T38, T45, T51; Bit diameter: 45mm-127mm);
Couplings sleeves- manufactured with a middle stop to prevent walking along the thread. Include couplings sleeve (threaded R22, R25, R28, R32, R38, T38, T45, T51)
Shank adapters - carburized and manufactured with tight tolerances and controlled straightness.
4. DTH hammers and DTH bits (Down The Hole Drilling)
Offer IR hammer, DHD3.5, DHD340a, DHD360, DHD380, and low pressure hammers CIR65a, CIR90, CIR110, CIR150, CIR170 etc. DTH bits: 60mm-254mm bits with flat face, concave design fit for the ingersoll-rand model etc.
5. Excavate coal cutter bits
Include all kinds of round cutter bit and flat cutter bits for excavate coal machine. Such as KTU76, KTU82, KTU84, KTU85, KTU92, KTU94, KTU95, KTU118 and coal bolting bit and coal bolting rod.
6. All kinds of casing bits for shield machine and construction tools.
7. Round road planning bit for road milling machine and machine.
Shank diameter=19.4mm, 25mm, 30mm, 33mm, 38mm, etc.
8. Blast furnace tap hole drill tools. (Rod, Cross bits, button bits and X-type bits etc).
| Product Name: | Conical Shank Bit Mining Teeth |
| Description: | rock drilling tools, construction drilling tools, mining tools, road milling tools, trenching tool,shield cutters and other related products. |
| Material: | carbide steel |
| MOQ: | 50PCS |
| Type | U82, U84, U85, U92, U94, U95, U47 ,S100 , S120,S150etc. |
| Diameter | 19-35mm |
| Use | Mining and drilling |
| Color | According to the customer request |
Liaocheng Kaituo Construction Machinery Co., Ltd is the professional manufacturer of Rock Drilling Tools, Down the Hole Drilling Tools and Mining Tools. Our main products are "KATO" brand of rock drilling tools, Down the hole drilling tools, Mining tools, Air hose for mining and Concrete vibrator series etc. Our products are widely used in cutting mountains, mining, railway, road building and energy supply construction etc. Our company has the advanced scientific research and the production experience, Our products are interchangeable with various products manufactured by Sandvik, Atlas Copco, Kennametal, Betek, Wirtgen etc.
Since it was found, our company proposed core business philosophy "good faith seeking win-win", and ran out of a production, modern management road of "customer-centric, market-oriented, science and technology, with quality and development, to management for efficiency" with the times, blaze new trails, efforts to build a more excellent " KATO" brand.
All staff of our company warmly welcome friends all over the world to cooperate.
