| Prod Model: |
SHA033 |
| Markets: |
North America,South America,Eastern Europe,Africa,Mid East,Eastern Asia |
Product Description
Expanded plate mesh machine
The machine produced by our company is high technology, and high practicability, It can produce steel plate mesh, aluminum plate mesh, titanium plate mesh and some other material mesh.
The machines are used for punching all kinds of expand plate mesh in construction, common hardware, window and door, machine protecting etc.
Feeding mechanism passes the chain link by the main engine directly, the movement accurate is reliable.
The times of feed mechanism punching shear start from 0, it can shear at will scope.
Type: SH25-16
Pounding thickness: ≤ 1.2mm
Pounding width: ≤ 1000mm
Stocks per minute: 160/min
Distance of feeding: 0-1.2mm
Length of the mesh: ≤ 25mm
Press plate pressure: 160KN
Power: 3KW
Overall weight: 2.5T
Outside size (L*W*H): 1090 *710 *1450mm
(I want to tell you that the mesh in your requirement can be made by one machine. So there is no need to buy two machines. )
The FOB tianjin port price for the type machine is 7000.00USD/set
The delivery time is 20 days.
The payment term is 30% T/T in advance 70% according to the copy of B/L
|
Type |
SH25-6.3 |
SH25-16 |
SH25-25 |
SH25-63 |
SH25-125 |
|
Pounding thickness |
≤ 1.0mm |
≤ 1.2mm |
≤ 1.5mm |
≤ 2.5mm |
≤ 6mm |
|
Pounding width |
≤ 500mm |
≤ 1000mm |
≤ 1250mm |
≤ 2000mm |
≤ 2500mm |
|
Stocks per minute |
230/min |
160/min |
130/min |
70/min |
40/min |
|
Distance of feeding |
0-1.15mm |
0-1.2mm |
0-1.2mm |
0-4mm |
0-7mm |
|
Length of the mesh |
≤ 20mm |
≤ 25mm |
≤ 30mm |
≤ 100mm |
≤ 250mm |
|
Press plate pressure |
63KN |
160KN |
250KN |
630KN |
1250KN |
|
power |
2.2KW |
3KW |
4KW |
11KW |
22KW |
|
Overall weight |
1.2T |
2.5T |
3T |
10T |
18T |
Outside size
L*W*H mm |
1090 *710 *1450 |
1800 *1400 *1870 |
1740 *1400 *2010 |
3560 *3500 *2300 |
5800 *3270 *1925 |
Anping ShengHua Metal Wire Mesh Factory located in the famous "silk screen of the township" --- Hebei Anping county, is a large enterprise that produce and sale kinds of wire mesh machines and wire mesh products, is a professional enterprise that gather design and produce wire mesh machine, produce wire mesh products and processing and trade integrative. We have been a "sophisticated quality, timely delivery, reasonable prices, excellent service" for the purposes of customer service, and in production principles, and won new and old clients of the masses.
Company equipment, advanced processes, internal management science, quality assurance system, company-based, reputable, trusted by both domestic and foreign customers. ISO9001: 2000 purchased products through international quality certifications, products are exported to Southeast Asia, the Middle East, the United States, Japan, Africa and other countries and regions.
Main products: Wire Mesh Machine: Wire Mesh: Stainless steel wire mesh, Chain link fence, Welded wire mesh, Wire mesh fence, Hexagonal wire netting; Chain link fence machine, Non shuttle weaving machine, Crimped wire mesh machine, Barbed wire machine, Razor barded wire machine, Window screening machine, Welded wire mesh machine, Expanded metal machine, Keel equipment, Clean ball machine, Wiredrawing machines; Expanded metal mesh etc. Widely used in petroleum, chemical, construction, civil, shield and other various industries. Products and exports throughout Europe, Africa, Southeast Asia and other countries and regions.
I always adhere to the company to survive the quality, credibility and development to the purposes and is willing to make friends in the world, for prosperity and development of screen industries, and community service go hand in hand to create
Brilliant.
Silk Affect Four Seas heart, woven Five Continents intelligence network. Anping Shenghua Metal Wire Mesh Machine Factory let you use the most favourable prices, the quickest way to buy most of their products.
While few managers welcome friends to discuss operational plant, let us go hand in hand for a better tomorrow!
