| Prod Model: |
Various |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
ISO9001,ISO14000 |
| Installation: |
Under Our Engineeer's Guide |
| After Sale Service: |
for The Whole Using Life |
| Design: |
by Our Professional Engineer |
| Tube Rev(R/Min): |
40.56-28.8 |
| Ball Quantity(T): |
0.5-95 |
| Power(Kw): |
15-1250 |
| Shipping Port: |
Qingdao,Shanghai,Tianjin |
| Spare Parts: |
We Offer |
| Advantage: |
Professional Manufacture |
| Motor Type: |
AC Motor |
| Condition: |
New |
| Type: |
Raw Mill |
| Application: |
Abrasive Materials |
Product Description
Raw mill is mainly used in grinding raw materials and end products in cement plant. It is also suitable for various ores and other materials metallurgy, mine, chemical and construction. Besides, it has two forms of milling, one is an open form, and the other is a recycle close form equipped with powder concentrator. It is widely applied in many industries and has convenient operation.
It has many advantages such as, strong adaptability, continuous production, large crushing ratio, easy to adjust the size of the products. And it is suitable for both dry production and wet production, also can allow the milling and drying processing simultaneously.
Introduction of Raw Mill
Raw mill is mainly used for grinding raw materials in cement plant. It can also be used to grind various ores and other materials in metallurgy, chemical industry, electric power and other industries. It is not only suitable for open circuit grinding, but also can work with powder separator for closed-circuit grinding.
Structure of Raw Mill
Raw mill is mainly composed of feeding part, discharging part, rotating part, transmission part (reducer, pinion, electric motor and electric control) and so on. Its hollow shaft is made of cast steel and inner lining is detachable and can be replaced. The rotating big gear is processed by casting hobbing machine. The inside of the cylinder is equipped with wear-resistant liners. Raw mill runs steadily and reliably.
Advantages of Raw Mill
Raw mill has many advantages such as, strong adaptability, continuous production, large crushing ratio, and easy to adjust the fineness of products. It is capable of dry production as well as wet production. Grinding and drying can be achieved simultaneously by raw mill.
Company Name: Henan Zhengzhou Mining Machinery Co., Ltd.
Official Website: http://www.inczk.com/ & http://www.zkcomp.com/
24-hour Free Sales Consulting Phone: 861-0371 -5590 2866.
Company Address: Qiaolou caizhai industrial estate, Xingyang city, Henan Province
Please pay attention to the company's other products:
Price of rotary kiln: http://www.zkcomp.com/calcining/558. Html
Rotary Kiln: http://www.inczk.com/Products/459. Html
Preheater: http://www.zkcomp.com/calcining/605. Html
Cement Mill: http://www.inczk.com/Products/460. Html
Rotary Dryer: http://www.zkcomp.com/calcining/564. Html
Raw Mill: http://www.inczk.com/Products/1373. Html
Ball Mill: http://www.zkcomp.com/grinding/582. Html
| Specification | Tube Rev | Ball Quantity | Feeding | Discharging-material Size | Output | Power | Remark |
| (r/min) | (t) | (mm) | (mm) | (t/h) | (kw) |
| Φ750×750 | 40.56 | 0.5 | ≤20 | 0.074-0.3 | 0.18-0.5 | 15 | energy saving style |
| Φ750×1060 | 49.6 | 0.6 | 0-12 | 0.074-0.4 | 0.14-0.34 | 4 | energy saving style |
| Φ750×1800 | 49.6 | 0.1 | 0-12 | 0.074-0.5 | 0.55-1.11 | 7.5 | energy saving style |
| Φ900×900 | 40 | 0.67 | ≤60 | 0.074-0.6 | 0.23-0.74 | 22 | energy saving style |
| Φ900×900 | 39 | 0.7 | ≤40 | 0.074-0.6 | 0.3-1.2 | 7.5 | wet lattice |
| Φ900×900 | 39 | 0.7 | ≤40 | 0.074-0.6 | 0.3-1.1 | 7.5 | wet overflow |
| Φ900×1200 | 38 | 0.3 | ≤40 | 0.074-0.6 | 0.2 | 5.5 | dry style |
| Φ900×1800 | 40 | 1.6 | ≤60 | 0.074-0.89 | 0.58-2 | 30 | energy saving style |
| Φ900×1800 | 39 | 0.85 | ≤40 | 0.074-0.89 | 0.6-2.1 | 15 | wet lattice |
| Φ900×1800 | 39 | 0.85 | ≤40 | 0.074-0.89 | 0.5-2.0 | 15 | wet overflow |
| Φ900×2100 | 41 | 1.7 | 0-15 | 0.074-0.89 | 0.69-1.30 | 15 | energy saving style |
| Φ900×2100 | 37 | 1.73 | ≤15 | 0.074-0.89 | 0.4-2 | 18.5 | dry lattice |
| Φ900×2400 | 39 | 2.1 | ≤40 | 0.074-0.89 | 0.7-2.8 | 18.5 | wet lattice |
| Φ900×2400 | 39 | 2.1 | ≤40 | 0.074-0.89 | 0.6-2.5 | 18.5 | wet overflow |
| Φ900×3000 | 36 | 2.7 | ≤20 | 0.075-0.89 | 1.1-3.5 | 22 | dry style |
| Φ900×3000 | 39 | 5.8 | ≤25 | 0.075-0.89 | 0.8-3.1 | 22 | wet lattice |
| Φ900×3000 | 39 | 5.8 | ≤25 | 0.075-0.89 | 0.7-2.8 | 22 | wet overflow |
| Φ1200×1200 | 34 | 5 | ≤25 | 0.075-0.89 | 0.3-3 | 18.5 | wet lattice |
| Φ1200×1200 | 34 | 5 | ≤25 | 0.075-0.89 | 0.3-2.5 | 18.5 | wet overflow |
| Φ1200×1200 | 31.3 | 2.4 | ≤20 | 0.074-0.6 | 0.20-2.19 | 37 | energy saving |
| Φ1200×1600 | 35 | 2.5 | 0-20 | 0.074-0.6 | 0.80-2.0 | 18.5 | energy saving |
| Φ1200×2000 | 35 | 3 | 0-20 | 0.074-0.6 | 1.1-2.6 |
| energy saving |
| Φ1200×2400 | 31.3 | 4.8 | 0-20 | 0.075-0.3 | 0.4-5.8 | 45 | energy saving |
| Φ1200×2400 | 34 | 9 | ≤25 | 0.075-0.3 | 0.5-6 | 30 | wet lattice |
| Φ1200×2400 | 34 | 9 | ≤25 | 0.075-0.3 | 0.5-5 | 30 | wet overflow |
| MQG1200×2400 | 32 | 4.8 | ≤20 | 0.074-0.6 | 1.5-2 | 45 | dry style |
| Φ1200×2800 | 35 | 4.22 | ≤25 | 0.074-0.6 | 1.5-3.7 | 37 | dry style |
| Φ1200×2800 | 35 | 4 | 0-20 | 0.074-0.6 | 1.42-3.8 | 30 | energy saving |
| Φ1200×3000 | 34 | 11 | ≤25 | 0.074-0.6 | 0.6-7 | 37 | wet lattice |
| Φ1200×3000 | 34 | 11 | ≤25 | 0.074-0.6 | 0.6-6 | 37 | wet overflow |
| Φ1200×3000 | 32 | 5 | ≤25 | 0.074-0.4 | 1.6-5 | 45 | dry style |
| MB1200×3000 | 28 | 7.2 | ≤25 | 0.074-0.4 | 1.5-8 | 45 |
|
| Φ1200×4500 | 33 | 13 | ≤25 | 0.074-0.4 | 0.7-8 | 45 | wet lattice |
| Φ1200×4500 | 33 | 13 | ≤25 | 0.074-0.4 | 0.7-7 | 45 | wet overflow |
| MQG1200×4500 | 30 | 5.2 | ≤25 | 0.074 | 1.5 | 55 |
|
| Φ1500×1500 | 29.2 | 4 | <25 | 0.074-0.85 | 1-3.5 | 60 |
|
| Φ1500×1500 | 31 | 9 | ≤25 | 0.074-0.4 | 1.5-7 | 45 | wet lattice |
| Φ1500×1500 | 31 | 9 | ≤25 | 0.074-0.4 | 1.5-6 | 45 | wet overflow |
| φ1500×1800 | 28 | 7 | ≤25 | 0.074-0.4 | 1 | 11 |
|
| Φ1500×3000 | 32.7 | 10.4 | <25 | 0.074-0.85 | 2-6.8 | 95 | energy saving |
| Φ1500×3000 | 31 | 17 | ≤25 | 0.074-0.4 | 3-11 | 75 | wet lattice |
| Φ1500×3000 | 31 | 17 | ≤25 | 0.074-0.4 | 3-10 | 75 | wet overflow |
| MBJ1500×3000 | 26 | 10 | ≤25 | 0.074-0.4 | 3-15 | 75 | wet rod mill |
| MQ1500×3500 | 31 | 8.2 | 0-25 | 0.074-0.4 | 3.3-8.2 | 75 | cone energy saving |
| MQG1500×4500 | 28.8 | 10 | ≤25 | 0.074-0.4 | 3-4 | 110 | dry style |
| Φ1500×4500 | 30 | 23 | ≤25 | 0.074-0.4 | 4-12 | 110 | wet lattice |
| Φ1500×4500 | 30 | 23 | ≤25 | 0.074-0.4 | 4-11 | 110 | wet overflow |
| MQG1500×5700 | 28.8 | 12 | ≤25 | 0.074-0.4 | 3-5 | 130 | dry style |
| Φ1500×5700 | 28 | 10.5 | 0-25 | 0.074-0.6 | 3.5-9.5 | 130 | energy saving |
| Φ1500×5700 | 30 | 25 | ≤25 | 0.074-0.6 | 4-14 | 130 | wet lattice |
| Φ1500×5700 | 30 | 25 | ≤25 | 0.074-0.6 | 4-13 | 135 | wet overflow |
| MQG1500×6400 | 28.8 | 13 | ≤25 | 0.074-0.4 | 3-5 | 130 | dry style |
| MQG1830×3000 | 26.8 | 14 | ≤25 | 0.074-0.4 | 6-16 | 130 | wet lattice |
| MQG1830×3000 | 26.8 | 14 | ≤25 | 0.074-0.4 | 6-15 | 130 | wet overflow |
| Φ1830×3000 | 25.4 | 11 | ≤25 | 0.074-0.4 | 4-10 | 130 | energy saving |
| MQ1830×3600 | 24.23 | 11 | 0-25 | 0.074-0.4 | 6.6-18.5 | 130 | wet energy saving |
| Φ1830×4500 | 26.8 | 31 | ≤25 | 0.074-0.4 | 6-18 | 180 | wet lattice |
| Φ1830×4500 | 26.8 | 31 | ≤25 | 0.074-0.4 | 6-17 | 180 | wet overflow |
| Φ1830×4500 | 25.4 | 15 | ≤25 | 0.074-0.4 | 4.5-12 | 155 | dry style |
| Φ1830×4500 | 24 | 15 | ≤25 | 0.074-0.4 | 4-19 | 155 | ball mill |
| Φ1830×5400 | 24.5 | 15 | ≤25 | 0.074-0.4 | 5-7 | 210 | wet overflow |
| Φ1830×6400 | 24.1 | 21 | ≤25 | 0.074-0.4 | 6.5-15 | 210 | wet overflow |
| MQG1830×6400 | 24.5 | 19 | ≤25 | 0.074-0.4 | 5-7 | 210 | dry style |
| Φ1830×6400 | 26.8 | 19 | ≤25 | 0.074-0.4 | 6-19 | 210 | wet overflow |
| Φ1830×6400 | 24 | 23 | ≤25 | 0.074-0.4 | 6.5-15 | 210 | wet lattice |
| Φ1830×7000 | 24.1 | 23 | ≤25 | 0.074-0.4 | 7.5-17 | 210 | dry energy saving |
| MQG1830×7000 | 24.5 | 20 | ≤25 | 0.074-0.4 | 6-8 | 245 | dry style |
| Φ1830×7000 | 24.5 | 21 | 0-25 | 0.074-0.6 | 4-35 | 210 | wet energy saving |
| Φ1830×7000 | 24.5 | 20 | ≤25 | 0.074-0.6 | 6-22 | 210 | wet lattice |
| Φ1830×7000 | 24.5 | 20 | ≤25 | 0.074-0.6 | 6-21 | 210 | wet overflow |
| Φ2100×2100 | 24 | 28.5 | ≤25 | 0.074-0.6 | 6-33 | 180 | wet lattice |
| Φ2100×2100 | 24 | 28.5 | ≤25 | 0.074-0.6 | 6-32 | 180 | wet overflow |
| Φ2100×3000 | 23.7 | 15 | ≤25 | 0.074-0.4 | 6.5-36 | 180 | dry style |
| Φ2100×3000 | 23.8 | 18 | < 25 | 0.074-2.36 | 6-33 | 180 | energy saving ball mill |
| MB2100×3000 | 22 | 20 | ≤25 | 0.074-2.36 | 14-35 | 210 | wet |
| 2100×3600 | 23.8 | 15 | 0-30 | 0.074-0.4 | 12-30 | 180 | cone energy |
| Φ2100×3600 | 22 | 22.9 | ≤25 | 0.074-0.4 | 7.6-28 | 210 | dry style |
| Φ2100×3600 | 24 | 45 | ≤25 | 0.074-0.4 | 7-39 | 210 | wet lattice |
| Φ2100×3600 | 24 | 45 | ≤25 | 0.074-0.4 | 7-38 | 210 | wet overflow |
| MBJ2100×3600 | 20 | 25 | ≤25 | 0.074-0.4 | 15-40 | 210 | wet rod mill |
| Φ2100×4500 | 23.7 | 24 | ≤25 | 0.074-0.4 | 8-43 | 245 | dry style |
| Φ2100×4500 | 24 | 49 | ≤25 | 0.074-0.4 | 8-43 | 240 | wet lattice |
| Φ2100×4500 | 24 | 49 | ≤25 | 0.074-0.4 | 8-41 | 240 | wet overflow |
| Φ2200×6500 | 21 | 31 | ≤25 | 0.074-0.4 | 14-26 | 380 | dry style |
| Φ2200×7500 | 21 | 33 | ≤25 | 0.074-0.8 | 16-29 | 380 | dry style |
| MQG2200×9000 | 21.4 | 34 | ≤25 | 0.074-0.8 | 8-10 | 475 | dry |
| Φ2400×3000 | 22 | 50 | ≤25 | 0.074-0.8 | 7-90 | 240 | wet |
| Φ2400×3600 | 22 | 50 | ≤25 | 0.074-0.8 | 9-47 | 240 | wet |
| MQG2400×7000 | 20.4 | 36 | ≤25 | 0.074-0.8 | 10-14 | 475 | dry |
| MQG2400×8000 | 20.4 | 42 | ≤25 | 0.074-0.8 | 10-14 | 560 | dry |
| MQG2600×8000 | 19.6 | 52 | ≤25 | 0.074-0.8 | 16-20 | 630 | dry |
| Φ2700×2100 | 21 | 70 | ≤25 | 0.074-0.8 | 9-80 | 240 | wet |
| Φ2700×2100 | 21 | 70 | ≤25 | 0.074-0.8 | 9-78 | 240 | wet |
| MQ2700×3600 | 20.6 | 39 | 0-35 | 0.074-0.8 | 31-65 | 380 | energy saving |
| Φ2700×3600 | 21 | 46 | ≤25 | 0.074-0.8 | 12-125 | 380 | wet lattice |
| Φ2700×3600 | 21 | 46 | ≤25 | 0.074-0.8 | 12-120 | 380 | wet overflow |
| MBJ2700×3600 | 18 | 45 | ≤25 | 0.074-0.8 | 18-123 | 350 |
|
| Φ2700×4000 | 21 | 53 | ≤25 | 0.074-0.8 | 12-1145 | 380 | wet lattice |
| Φ2700×4000 | 21 | 53 | ≤25 | 0.074-0.8 | 12-140 | 380 | wet overflow |
| Φ2700×4500 | 20 | 53 | ≤25 | 0.074-0.8 | 12-150 12-145 20-25 | 430 | wet lattice |
| Φ2700×4500 | 20 | 53 | ≤25 | 0.074-0.8 | 430 | 100 |
| MQG3000×9000 | 18.3 | 78 | ≤25 | 0.074-0.8 | 1000 | 150 |
| Φ3200×4500 | 18 | 69 | ≤25 | 0.074-0.8 | 600 | 126 |
| Φ3200×4500 | 18 | 69 | ≤25 | 0.074-0.8 | 600 | 125 |
| Φ3600×4500 | 17 | 90 | ≤25 | 0.074-0.8 | 850 | 160 |
| Φ3600×4500 | 17 | 90 | ≤25 | 0.074-0.8 |
| 850 | wet overflow |
| Φ3600×6000 | 17 | 95 | ≤25 | 0.074-0.8 |
| 1250 | wet lattice |
| Φ3600×6000 | 17 | 95 | ≤25 | 0.074-0.8 |
| 1250 | wet overflow |
