| Prod Model: |
reference to the form |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rev: |
24.5 |
| Factory Established: |
1956 |
| Factory Area: |
55000m2 |
| Color: |
Grey |
| Grinding Body: |
20t |
| Power: |
245 |
| Feeding Size: |
<25mm |
| Installation: |
Under Our Engineer's Guide |
| Certificate: |
ISO9001: ISO14000 |
| After Sale Service: |
for The Whole Using Life |
| Motor Type: |
AC Motor |
| Condition: |
New |
| Type: |
Ore Grinder |
| Rotationl Speed: |
See Instructions |
| Materials: |
See Instructions |
| Application: |
See Instructions |
| Motor Power: |
See Instructions |
Product Description
Ball Mill For Metallurgical Ore Dressing
Ball mill organization character:
By feeding department, the exiting material department, the transmission department (speed reducer, small transmission gear, electrical machinery, electric control) and so on main part composes. The midheaven axis uses the steel casting, the inside lining is detachable, rotates the big wheel to use the casting to roll the tooth processing, tube in vivo besets with by the wear-resisting backing, has the good resistance to wear. It revolves steadily, operation reliable.
Ball Mill Working Principle:
The Energy-Saving Ball Mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.
Features of Ball mill
1. Wide range of applications, simple structure and convenient maintenance;
2. Large capacity and continuous work are very obvious;
3. Barrel lining and grinding media can apply various abrasive materials;
4. Installation and adjustment are very convenient and easy to be operated
Company Name: Henan Zhengzhou Mining Machinery Co., Ltd.
Official Website: http://www.inczk.com/ & http://www.zkcomp.com/
24-hour Free Sales Consulting Phone : 861-0371 -5590 2866 .
Company Address: Qiaolou caizhai industrial estate, Xingyang city, Henan Province
Please pay attention to the company's other products:
Price of rotary kiln: http://www.zkcomp.com/calcining/558.html
Rotary Kiln:http://www.inczk.com/Products/459.html
Preheater:http://www.zkcomp.com/calcining/605.html
Cement Mill:http://www.inczk.com/Products/460.html
Rotary Dryer:http://www.zkcomp.com/calcining/564.html
Raw Mill:http://www.inczk.com/Products/1373.html
Ball Mill:http://www.zkcomp.com/grinding/582.html
Model | Rotationna speed
r/min | Ball load
t | Feeding size
mm | Output size
mm | Capacity
t/h | Power
kw | Weight
t |
| 900× 1800 | 36-38 | 1.5 | ≤ 20 | 0.075-0.89 | 0.65-2 | 18.5 | 4.6 |
| 900× 3000 | 36 | 2.7 | ≤ 20 | 0.075-0.89 | 1.1-3.5 | 22 | 5.6 |
| 1200× 2400 | 36 | 3 | ≤ 25 | 0.075-0.6 | 1.5-4.8 | 30 | 12 |
| 1200× 3000 | 36 | 3.5 | ≤ 25 | 0.074-0.4 | 1.6-5 | 37 | 12.8 |
| 1200× 4500 | 32.4 | 5 | ≤ 25 | 0.074-0.4 | 1.6-5.8 | 55 | 13.8 |
| 1500× 3000 | 29.7 | 7.5 | ≤ 25 | 0.074-0.4 | 2-5 | 75 | 15.6 |
| 1500× 4500 | 27 | 11 | ≤ 25 | 0.074-0.4 | 3-6 | 90 | 21 |
| 1500× 5700 | 28 | 12 | ≤ 25 | 0.074-0.4 | 3.5-6 | 130 | 24.7 |
| 1830× 3000 | 25.4 | 11 | ≤ 25 | 0.074-0.4 | 4-10 | 130 | 28 |
| 1830× 4500 | 25.4 | 15 | ≤ 25 | 0.074-0.4 | 4.5-12 | 155 | 32 |
| 1830× 6400 | 24.1 | 21 | ≤ 25 | 0.074-0.4 | 6.5-15 | 210 | 34 |
| 1830× 7000 | 24.1 | 23 | ≤ 25 | 0.074-0.4 | 7.5-17 | 245 | 36 |
| 2100× 3000 | 23.7 | 15 | ≤ 25 | 0.074-0.4 | 6.5-36 | 210 | 34 |
| 2100× 4500 | 23.7 | 24 | ≤ 25 | 0.074-0.4 | 8-43 | 245 | 42 |
Henan Zhengzhou Mining Machinery Co., Ltd, was established in 1956 and located in Xingyang of Zhengzhou City of Henan Province, specially produces metallurgical machinery. It covers an area of more than 55000m2 and various building area of 28000 m2. It has the annual income of more than RMB180million in 2008 and now the fixed assets of over RMB80 million. In the plant, there are branches and workshops of cast iron, cast steel, forging, heavy machine tool processing, rivet welding and heat treatment etc. Its perfect and complete equipment, advanced detection means, strong technical force establish good foundation for the reliable production.
Main products include: Jaw style, hammer style, impact style and roll style crusher; Ball mill, direct fired drier, rotary kiln, preheater, coker, magnetic separator, flotation machine, classifier, feeder, hoisting machine and conveyor etc. These complete sets of machinery for cement building material, metallurgy, coking and chemical smelting etc are sold well in the world. Our company also has professional installation and construction teams and perfect after-sales service guaranty system.
With the development of the People's Republic of China, Henan Zhengzhou Mining Machinery Co., Ltd undergoes frequent difficulties and has accomplished over 50 years' brilliant history. Initially from the manufacturing of original single machine till today's series of and complete sets of mining metallurgical machinery, it has made great contribution to the development and utilization of mineral resources of our country. For many years, each spot check and annual examination carried by National Mining Machinery Quality Supervision and Inspection Center for our products is acceptable and our company is always appointed as Credible and Reputed Enterprise by Henan Provincial Administration of Industry and Commerce.
Henan Zhengzhou Mining Machinery Co., Ltd will continue providing excellent products and service for our society, with the guideline of "survival by quality, development by good faith, users supreme". Our company would make sincere cooperation with all circles for mutual benefit and common development.
