| Prod Model: |
NRSDH5 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity: |
500-15000L |
| Voltage: |
380V 450V 110V 220V |
| Materials: |
Stainless Steel |
| Application: |
Cream |
| Customized: |
Customized |
Product Description
Milk centrifuge separator
1. Application: Medical, chemical, food
2. Disc centrifuge
3. High speed separator
4. Large capacity
Main features
Milk separator machine is mainly used skim milk, whey protein isolate, butter, wheat shock shower, casein, cheese production, anhydrous butter centrifuge enrichment and other production processes for medium to large dairy industry enterprises. Equipment uses a closed structure, with milk contact parts made of stainless steel, in line with national food hygiene standards. Device according to user requirements, can also be used in the milk, milk residue, after condensation casein, the protein and whey protein isolate, and whey clarification and purification.
Main parts of the equipments
1. Access device
2. Rotor drum
3. Paring disc device
4. Drive system
5. Stainless steel cover
6. Engine base
7. Motor.
Feature
1. Machine starts the friction to start off, about six to ten minutes. The machine runs smoothly, low noise and vibration, the installation path is very easy to operate.
2. The bearings use imported FAG, transducer using Japan brand " FUJI", the main strengthen parts of Roller body and Roller cover use 2Cr13, and the other parts of contacted materials such as Disc all use 316L.
3. The Stainless steel cover use SUS304
4. The base use casting steel, coating does the same way as ship bottom.
Wenzhou wanyuan food machinery factory— — Milk Cream Separator
The below is Milk Cream Separator specifications:
| Model | NRSDH5 | NRSDH10 | NRSDH20 | NRSDH30 |
| Output | 500L/h | 1000L/h | 2000L/h | 3000L/h |
| Drum Speed | 8000rpm | 7320rpm | 7320rpm | 6500rpm |
| Motor Power | 2.2KW | 4KW | 5.5KW | 7.5KW |
| Slagging mode | Auto-control | Auto-control | Auto-control | Auto-control |
| Output Pressure | 100-350KPa | 100-350KPa | 100-350KPa | 100-350KPa |
Working
Condition | Semi-closed | Semi-closed | Semi-closed | Semi-closed |
Separation
temperature | 40-45oC | 40-45oC | 40-45oC | 40-45oC |
| Fat content | <0.04% | <0.04% | <0.04% | <0.04% |
| Dimensions | 700*550
*800mm | 800*600
*1250mm | 1000*6200
*1400mm | 1100*650
*1250mm |
Our factory specializes in producing and selling processing equipment for dairy products, beverage, brewage, meat and poultry. Our main products include automatic double-tank sterilizing boilers, electric heating sterilizing boilers, emulsifying tanks, sugar dissolving tanks, cooling and heating cylinders, concentrating boilers, seed tanks, jacketed boilers, and direct cooling tanks.
Other food equipment can also be designed and manufactured according to customer requirements. The latest digital technology has been utilized for direct conversational programming and key parts have been carried out in mechanical machining, such as drilling, cutting, milling and grinding to ensure the ultimate precision. We have powerful technical force to independently and successfully design and manufacture products, completely realizing the simple and programmable operations of consistent products. We have some experienced experts and they can provide whole services for you from initial preparation, detailed construction and after-sales technique to spare part support.
At the same time, we combine our many years' experience to meet customer requirements and solve the difficulties of equipment technology. All our stainless steel equipment have reached sanitary equipment standard, which guarantees users with completely sanitary status through our abundant strength and a good reputation. We offer customers safe and reliable products and favorable prices.
