AISI 304 Sanitary Milk Pump
| Price: |
US $ 500-1500/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union |
| Prod Model: |
CP-5-24 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: |
Ss304 |
| Usage: |
Dairy &Food&Water |
| Fuel: |
Sanitary Centrifugal Pump |
| Pressure: |
High Pressure |
| Theory: |
Centrifugal Pump |
| Application: |
Food, Dairy, Water |
| Customized: |
Customized |
Product Description
Milk pump / Sanitary Beverage Pump 3L/H Flow Rate Pump
Specifications
1. Single stage, back pullout, SS covered
2. Food grade stainless steel, GMP standard
3. Competitive price, long serivce life
Overview
SP stainless steel milk pump is a special design has impeller and shaft sleeve are forged integrally, and directly installed on the output shaft of the motor.
Advantage: High concentricity of shaft, strong rigidity, small vibration and prolonged service life of mechanical seal.
Disadvantage: Only suitable for small power, the maximum power rate is 2.2kw.
Milk pump / Sanitary Beverage Pump 3L/H Flow Rate Pump
Applications
SP centrifugal pump is a sanitary centrifugal pump that meets the highest sanitary requirements for use in the food-processing and pharmaceutical, dairy, milk, bear industries.
Some of its uses include processes in the brewing, dairies and beverage industries in general, and with the appropriate options it can also be used in complex applications such as evaporators, concentrators, distillation towers, decanting of syrups, and purified-water loops in the pharmaceutical industry.
Working principle
Housed inside the casing, the impeller rotates in conjunction with the pump shaft. With this arrangement, the impeller blades convey energy to the fluid in the form of kinetic energy and pressure energy.
This pump is not reversible by simple reversal of the direction of rotation. The direction of rotation is clockwise when the pump is viewed from the rear side of the motor.
Technical parameters
Design and features
Different connections standard: DIN, SMS, JIS, ISO.
Open impeller manufactured with stainless steel investment casting technology.
Sanitary mechanical seal.
Pump certified according to 3A sanitary standards.
Very robust stainless steel cast lantern.
Pump support from AISI 304.
Wenzhou wanyuan food machinery factory
Milk pump / Sanitary Beverage Pump 3L/H Flow Rate Pump
Here below the sanitary beverage pump specification| Parts in contact with pumped media | AISI 316L or 304 |
| Other parts in stainless steel | AISI 304 |
| Gaskets (standard) | EPDM (FDA) |
| Mechanical seal (standard) | graphite/Sic/EPDM |
| Inside surface finishing | Ra < 0.4 um. |
| Outside surface finishing | Mirror polished |
Our factory specializes in producing and selling processing equipment for dairy products, beverage, brewage, meat and poultry. Our main products include automatic double-tank sterilizing boilers, electric heating sterilizing boilers, emulsifying tanks, sugar dissolving tanks, cooling and heating cylinders, concentrating boilers, seed tanks, jacketed boilers, and direct cooling tanks.
Other food equipment can also be designed and manufactured according to customer requirements. The latest digital technology has been utilized for direct conversational programming and key parts have been carried out in mechanical machining, such as drilling, cutting, milling and grinding to ensure the ultimate precision. We have powerful technical force to independently and successfully design and manufacture products, completely realizing the simple and programmable operations of consistent products. We have some experienced experts and they can provide whole services for you from initial preparation, detailed construction and after-sales technique to spare part support.
At the same time, we combine our many years' experience to meet customer requirements and solve the difficulties of equipment technology. All our stainless steel equipment have reached sanitary equipment standard, which guarantees users with completely sanitary status through our abundant strength and a good reputation. We offer customers safe and reliable products and favorable prices.
