| Prod Model: |
LM-860 |
| Markets: |
North America,Africa,Western Europe |
| Different Covering Sizes: |
860mm |
Product Description
Product name: Roll forming machine
Model No.
Trademark LM
Material spec: Colored steel sheet, galvanized steel sheet
Thickness of coil sheet: 0.3 - 0.8mm
Main motor power: 7.5kW
Forming speed: 10 - 16m/min
Hydraulic station power: 3kW
Quantity of stands about: 16 groups
Hydraulic pressure : 10 - 12Mpa
Controlling system : PLC
Index error of length: 10m - 2mm
Total weight: About 4500kg
Voltage: 380V 3 phase 60Hz or at buyer's requirement
Our roll forming machine can produce different kinds of steel panel tiles for roof and wall. The tiles is mainly used in temporary building site, steel constrcuture workshop, and other public building with fast building speed. It has advantage of pretty appearance, durable using and so on.
The metal sheet cold roll forming of us has characters of high spped, high production, good performance, low labor and save cost. All the above characters are the best selectons for producing the metal sheet cold rollform products.
The forming rollers is the key of roll forming machine. We use CAD to design and manufacture the rollers. After CNC lathe, the forming rollers will be harden by vacuum heat treatment and finished the profiles again. These processes make the more accurate forming rollers, avoid the deformation during heat treatment and ensure the rollers preciseness and wear-resisting ability
Liming Stamping Form Machine Manufactured Co., is a leading manufacturer for steel plate coiling machinery, roll-forming and automatic production lines. The products are mainly used in steel structure industry for producing C&Z shape purlin, load-bearing plate of buildings, wall and roof protective structure colorful steel plate, thermal insulation; Colorful decorating and protecting steel plates for high-grade steel structure residences; Environment industry anode plate and kathode plate lines for removing dust; Traffic-transport industry freeway guardrail plate, vehicle roll-forming materials; Logistics. Goods shelf pillar, holding beam; Cable bridge, Cabinet pillar and others collorary thin wall roll-forming materials serials-such as goods shelf board, kinds of cabinet screen plate. Then, it can also supply kinds of line of uncoiler, leveler, slitting recoiler, cut-to-length shear stacker.
Liming has advanced production equipment. Engineering personnel and technicians of Bohai are rich in experience of designing, developing, and manufacturing of machineries, They pay close attention to and keep up with the developing trend of technologies and adopt new technologies in the manufacturing of our machinery products, to keep them competitiveness. The products are characteristic of high efficiency, high flexibility and low production cost.
