| Prod Model: |
C5915V |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Inner Diameter: |
50mm-180mm |
| Outer Diameter: |
72mm-240mm |
| Width: |
40mm-100mm |
Product Description
Segment bearings are applied in the continuous caster, it can be named caster bearings, and it is called CARB bearings on the aboard, it is a new type of radial roller bearings, its unique design combines the spherical roller bearings and self-aligning capability axial cylindrical roller bearings displacement characteristics, it has a compact section of needle bearings on metallurgy continuous casting machine, paper machine and other machinery are widely used.
The features of Kunlun brand segment bearings(also caster bearing, CARB bearing) which Beizhou bearing manufactures is below:
1). Axial displacement can be allowed in single direction is the width of 10%
2). Maximum angle error can be up to 0.5 °
3). Be used to bear radial load conditions, exclusively for non-locating bearing
4). Unique internal geometry to ensure that the load between the rollers and raceways can always remain evenly distributed
The advantages of full complement roller structure:
1). Self-guided rolling element
2). Dynamic load of bearing is improved
3). Reduced the speed limit
The advantages of sealed full complement roller structure:
1). Be consisted of the small and medium full complement rollers which are fit in this conditions of low ratation speed
2). Be used for the polluted environment
3). Needn't maintenance, sealed for whole life
The Kunlun brand segment bearings(also caster bearing, CARB bearing) has no cage as for due to it is full complement roller, we made the speical heat treatment during the manufacturing, so the segment bearings can be driven in the higher temperature for long time and the shape dimension will not be changed. When the caster bearing is mounted on the shaft or bearing housing, the two bearing rings and full row rollerw must be centred accurately to each other, when installing the bearing, if the shaft and housing is located in the horizontal position it will be much better. If you must install the bearing on the vertical axis or vertical bearing housing, you should use the tool which can keep the alignment.
|
Model No. |
Shape Dimension (mm) |
Weight |
|
d |
D |
B |
Kg/SET |
|
|
|
|
|
|
|
C6910V |
50 |
72 |
40 |
0.54 |
|
C5915V |
75 |
105 |
40 |
1.1 |
|
C6915V |
75 |
105 |
54 |
1.4 |
|
C5916V |
80 |
110 |
40 |
1.2 |
|
C5918V |
90 |
125 |
46 |
1.68 |
|
C4020V |
100 |
150 |
50 |
3.05 |
|
C5020V |
100 |
150 |
67 |
4.3 |
|
C3120V |
100 |
165 |
52 |
4.4 |
|
C4022V |
110 |
170 |
60 |
5.15 |
|
C4122V |
110 |
180 |
69 |
7.05 |
|
C4024V |
120 |
180 |
60 |
5.5 |
|
C4026V |
130 |
200 |
69 |
8.05 |
|
C4028V |
140 |
210 |
69 |
8.55 |
|
C4030V |
150 |
225 |
75 |
10.5 |
|
C4130V |
150 |
225 |
100 |
20.5 |
|
C4032V |
180 |
240 |
80 |
12.6 |
Wuxi Kunlun Transmission Equipment Co., Ltd is the subsidiary of Beijing Beizhou Bearing Co., Ltd., we Beizhou Bearing are located in Beijing, and Beizhou Bearing has 46 years design and manufacturing experiences of "Kunlun" brand bearings, especially for the rolling mill bearings, we Beizhou Bearing own three manufacturing factories which they are separately located in Beijing, Dalian, Luoyang. The main application of Kunlun bearings is rolling mill, metallurgical, mechanical industries etc.
Our bearing series include rolling mill bearings, four-row cylindrical roller bearings, double-row cylindrical roller bearings, backing bearings, deep groove ball bearings, four point angular contact ball bearings, single row angular contact ball bearings, double row angular contact ball bearings, self-aligning roller bearings, double-row tapered roller bearings, imperial double-row tapered roller bearings, four-row tapered roller bearings, inch four-row tapered roller bearings, sealed four-row tapered roller bearings, thrust ball bearings, double direction thrust tapered roller bearing, thrust ball bearings, double direction thrust tapered roller bearings, thrust self-aligning roller bearings, full complement thrust tapered roller bearings, special bearings of conticaster, high-speed wire rod rolling mill bearings, split bearings, rolling mill bearing seal, etc.
