| Prod Model: |
SD-0002 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: Steel Frame & Purlin Machine: |
Model Numbe : C |
| Power(W):T 7.5kw: |
Certification: ISO9001-2000 |
| Forging Forming Method: |
Tire Mold Forging |
Product Description
Specifications
Adjustable C Purlin Roll Forming Machine
1) Electrical button for size changing
2) Size changeble by 1mm
C shaped steel roll forming machine is comprised of manual uncoiler, infeed guides& levelling roll, punch stations, main roll forming machine, cutting equipment, main drive, control cabinet, output table.
Technical Parameters
Rollform material specification: C80-300, thickness: 1-3mm, yield strength: 250Mpa max.
Forming speed: 0-12 m/min
Rollers group: 16 groups
Levelling groups; 7 group
Rollers material: GCr15 quenching treatment, HRC58-62
Main shaft material: 45# fine steel, heat process
Main axis diameter; 75mm
Main motor power: 15KW
Hydraulic station power: 7.5KW
Total weight: About 12, 000kg
Controlling system PLC
Product range: All the types from 80 to 300
Our enterprise, set up in 2003, is the most powerful manufacturer in cold roll forming machinery production in North China.
Our factory is a leading manufacturer for steel plate coiling machinery, roll-forming and automatic production lines. The products are mainly used in steel structure industry for producing C&Z shape purlin, load-bearing plate of buildings, wall and roof protective structure colorful steel plate, thermal insulation; Colorful decorating and protecting steel plates for high-grade steel structure residences; Environment industry anode plate and kathode plate lines for removing dust; Traffice-transport industry freeway guardrail plate, vehicle roll-forming materials; Logistics. Goods shelf pillar, holding beam; Cable bridge, cabinet pillar and others collorary thin wall roll-forming materials serials-such as goods shelf board, kinds of cabinet screen plate. Then, it can also supply kinds of uncoiler, leveler, slitting recoiler, cut-to-length shear stacker.
We has advanced production equipment. Engineering presonnel and technicians of our factory are in experience of designing, developing, and manufacturing of machineries. They pay close attention to and keep up with the developing trend of technologies and adopt new technologies in the manufacturing of our machinery products, to keep them competitiveness. The products are characteristic of high effciency, high flexibility and low production cost.
Benefited from customers ins the first, success of our factory comes from success and development. We run this mind through the whole process from design and development of product to after-sales. We will design and manufacture the machinery strictly in accordance with your requirements.
Ours factory lies in China, the biggest developing country of the world, familiar with machinery industry especially steel plate processing industry of developing counties. The company produce steel plate processing machineries suitable developing countries as far as price and automation degree are concerned, saving time and funds for our customers.
We own the good after-sales service network, and can provide supports covering the whole proeess of purchasing, help you get the perfect machinery, make sure that we'll solve all problems when you use the machine conveniently and immediately, and we'll provide you considerate.
That some of our stamping machine sets has been sold to Canada, SouthKorea, Holand, Suriname, SriLanka, Malaysia, Vietnam, Nigeria, Tanzania, India, Azerbaijan, Vladivostok, Mongolia, Armenia, Chita, Kazakstan, Bolivia, Ukraine, Novosibirsk, Congo etc. Made us enter the intemational market.
Service and technology of our accompany you to create a bright future.
