Product Description
Convenient for operation
Hydraulic system is placed inside the machine body
Adjustable stroke and pressure according to the technology in the specified scope
Application
This series of hydraulic presses are used in the straightening, press-in, drawing bending, coining and forming technology forsheet, shaft and power products
Optional
Auxiliary work table
Precise straight system
Photo electricity protective device
Touching type industry display monitor
Proportion velocity modulation system
Hydraulic system heating, cooling system
Hits the material installment
PLC programmable controller
|
The main technical parameter of C-type hydraulic press |
|
Item |
Unit |
YXK1/2-100 |
YXK-200 |
YXK-250 |
YXK-315 |
YXK-500 |
YXK-630 |
YXK-800 |
YXK-1000 |
Note |
|
Nominal pressure |
KN |
1000 |
2000 |
2500 |
3150 |
5000 |
6300 |
8000 |
10000 |
The technical parameter may change according to the customer request |
|
Return strength |
KN |
150 |
240 |
245 |
390 |
950 |
600 |
1000 |
1250 |
|
Sliding block rtavel range |
mm |
500 |
500 |
500 |
500 |
500 |
500 |
500 |
500 |
|
Closed height |
mm |
450 |
450 |
450 |
450 |
600 |
600 |
600 |
600 |
|
Biggest open height |
mm |
950 |
950 |
950 |
950 |
1100 |
1100 |
1100 |
1100 |
|
Sliding block speed |
Idle |
mm/s |
200 |
200 |
200 |
200 |
200 |
200 |
250~300 |
250 |
|
Working |
8~20 |
7~20 |
12 |
10 |
15 |
12 |
15~25 |
6~15 |
|
Return |
180 |
180 |
180 |
180 |
180 |
180 |
180 |
180 |
|
Work table size |
L-R |
mm |
700 |
700 |
700 |
700 |
800 |
800 |
1100 |
1100 |
|
F-B |
700 |
700 |
700 |
700 |
800 |
800 |
1100 |
1100 |
|
Machine size |
L-R |
mm |
/ |
/ |
/ |
/ |
/ |
/ |
/ |
/ |
|
F-B |
/ |
/ |
/ |
/ |
/ |
/ |
/ |
/ |
|
Above ground high |
/ |
/ |
/ |
/ |
/ |
/ |
/ |
/ |
|
Electric motor power |
kw |
15 |
25 |
25 |
45 |
45 |
45 |
45+18.5 |
45+45 |
