Product Description
Features:
Four-column type
Cartridge valves with little shock, less leakage and reliable movements
Work with pre-setting pressure or pre-setting stroke, pressure can be held, time can be delayed and adjusted.
Adjustable pressure and stroke according to the technology in the stipulated scope
Three working ways: Adjusting, manual and semi-automatic
Application
This series of hydraulic presses are used in the drawing, blanking, bending, flanging, cold extruding, straightening, pressing-in, and forming technology for metal, plastics, abrasive, and insulator products.
Optional
Moving bolster
Buttering device for blanking
Photo-electricity protective device
Trades the mold to use the fluctuation guide rail and the trundle bracket
Mold fast clamp organization
The traveling schedule, the pressure, the speed number reveal, the numerical control installment
Touching type industry display monitor
Hydraulic system heating, cooling system
Hits the material installment
Trades mold car
Slide security hitch
The mold heating and warm controls the installment
PLC programmable control
Nearby pressure circle and actuation system
|
Nominal pressure |
KN |
1000 |
2500 |
3150 |
5000 |
6300 |
8000 |
10000 |
The technical parameter may change according to the customer request |
|
Return strength |
KN |
150 |
245 |
390 |
1000 |
600 |
1000 |
1250 |
|
Biggest opening height |
mm |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
|
Nominal pressure of hydraulic pad |
KN |
200 |
1000 |
630 |
1500 |
/ |
2500 |
4000 |
|
Travel range of hydraulic pad |
mm |
200 |
350 |
300 |
300 |
/ |
400 |
400 |
|
Travel range of sliding block |
mm |
900 |
900 |
900 |
900 |
900 |
900 |
900 |
|
Closed height |
mm |
600 |
600 |
600 |
600 |
600 |
600 |
600 |
|
Sliding block speed |
Idle |
mm/s |
300 |
100 |
200 |
200 |
120 |
250~300 |
300 |
|
Working |
8~20 |
12 |
10 |
15 |
12 |
15~25 |
13~20 |
|
Return |
110~230 |
120 |
150 |
100 |
150 |
150~200 |
250 |
|
Hydraulic pressure pad speed |
Rise |
mm/s |
150 |
40 |
100 |
100 |
/ |
80 |
50 |
|
Returning |
300 |
90 |
/ |
/ |
/ |
/ |
/ |
|
Work table size |
L-R |
mm |
850 |
2100 |
2500/3700 |
3000 |
4000 |
3600 |
4000/4100 |
|
F-B |
600 |
1400 |
1250/1400 |
2200 |
750 |
2400 |
2600/2300 |
|
Hydraulic pressure pad size |
L-R |
mm |
/ |
Φ 900 |
1500 |
2000 |
/ |
2300 |
3500 |
|
F-B |
/ |
800 |
1500 |
/ |
1300 |
1800 |
|
Work table carry capacity |
T |
/ |
/ |
10 |
/ |
/ |
15 |
30 |
|
Machine size |
L-R |
mm |
1725 |
4000 |
6100 |
4600 |
5400 |
10750 |
5800 |
|
F-B |
1270 |
2200 |
4500 |
3200 |
2050 |
6170 |
3100 |
|
Above ground high |
3400 |
5150 |
5600 |
5900 |
5200 |
6800 |
7400 |
|
Electric motor power |
kw |
15 |
25 |
47.3 |
74.4 |
51.5 |
144 |
180 |
|
Machine gross weight |
T |
47.2 |
32 |
52 |
105 |
65 |
156 |
185 |
