| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Package: |
Pallet ,Manmade Wooden Case or as Your Requirement |
| Certificate: |
ISO9001 SGS |
| Origine: |
Qingdao |
| Service: |
OEM and ODM |
| Size: |
Diameter 10-1000mm |
| Process: |
Casting and Machining |
| Deliverr Time: |
30 Days After Receiving The Payment |
| Type: |
Clay Wet Sand |
| Material: |
Cast Iron |
Product Description
With the new-style of lining in conical surface, the pulley change the traditional designing method and convenient to install and disassemble. The pulley has a high precision, and runs credibly. Through using linings of conical surface so it can be used in different installing sizes and occasions. The designing process is simplified escaping the trouble of re-processing, meantime improving the degree of the pulley's general use and standard state. Now it has been used widely in the engine power transmission.
Cast iron v belt pulley
1. Material: Cast iron GG25
2. Process: Machining phosphating
3. High strength
4. Corrosion resistance
Each pulley is strictly dynamically balanced with high precision dynamical balancing machining tools. Unbalanced volume corrected accurately.
Each pulley can be used safely and reliably.
Pully with Advantages:
1. More than 25-years experience in casting and machining
2. More than 8-years export experience
3. Packed with advanced equipment and ready for your OEM projects
4. Best quality control with kinds of testing machine and rich experienced engineers & inspectors.
5. Quality system is ISO9001-2008 qualified.
6. Competitive price supplied.
7. Rich experience in packing, loading and arrangement of shipment.
8. One-stop service supplied.
Questions you may care
1) our MOQ: Generally speaking is 1T, but if your products is interested enough, the MOQ can reduce.
2) our payment term: For mold: 50% pay in advance, 50% within one week after sample approval
For products: 30% pay in advance, 70% against copy of bill of lading
3) quoting elements: Drawing, material (detail material grade), weight and quantity
4) can we produce other products? Yes, of course, if you give me a drawing or sample, we can produce any metal thing for you.
| 1. Type: SPZ, SPA, SPB, SPC, 3V,5V,8V, Adjustable Pulleys,Multiwedge Pulleys/ Ploy-V Pulleys and customized Pulley etc. |
| 2. Bore: Pilot Bore and Taper Bore available. |
| 3. Material: Cast Iron,Gray Cast Iron and S.G. Cast Iron |
4. V Belt Pulley set with Belt available upon request. |
Qingdao Chifine Machinery Co., Ltd is One Famous Company in China Which Specialized in Various Metal Casting Products with Over 10 Years Experience Located in Qingdao China. It Covers a Comprehensive Range of Forging, Stamping, Sand Casting, Investment Casting, Die Casting and Machining and Was Widely Used in Agriculture Machinery, Motor Vehicle, Architecture, Railway and Engineering Chifine Has Accumulated Important and Valuable Experience in Design, Manufacturing and Customer Service Over These Years We Will Continue to Integrate Our Technical Superiority, Improve Process and Quality to Increase Market Share and Create More Brilliant Future.
Automative Casting Line:
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
• Product Size: 0-1000mm.
• Weight: 0.2kg-100kg
Resin Sand Casting
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Steel casting(ASTM/UNS; DIN; JIS; NF; BS; ISO)
• Product Size: 0-1500mm.
• Weight: 10kg-5000kg
Shell Mould Casting
Shell casting is one of resin sand casting process.
It is suitable for thin-wall casting parts, be free from porosity.
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Steel alloy; Aluminum alloy; Copper alloy.
• Product Size: 0-500mm.
• Weight: 50g-100kg.
• Wall thickness: 4-20mm
Lost Wax Casting
• Advanced wax-injection-machine and tool to ensure accurate wax-patten.
• Stable temperature and humidity environment make the wax-patten no deformation.
• Material:
Carbon steel; Stainless steel; Alloy steel.
Grey iron(GG20-GG35).
Ductile iron(GGG40-GGG60);
Malleable cast-iron
(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Aluminum alloy; Copper alloy.
• Casting size: 0-500mm.
• Casting weight: 50g-100kg
Stamping and Forging Line
• Stamping and forging equipment: 16T-300T press machine
• Automatic transport forging line
• Material: Carbon steel; Stainless steel; Alloy steel.
Aluminum alloy; Copper alloy.
Machining Shop
Our machining shop located in Qingdao, using the latest CNC equipment to provide our customer with high quality products.
• Horizontal and Vertical Machining Center
• CNC lathe and normal lathe
• CNC drilling and milling Center
• Other assistant equipment
