| Prod Model: |
LHm/5C |
| Markets: |
North America,South America,Eastern Europe,Oceania,Mid East,Eastern Asia,Western Europe |
| Working Pressure: |
Middle Pressure Pump |
| Position Of Pump Shaft: |
Horizontal Pump |
| Impeller Number: |
Single-Stage Pump |
| Influent Type Of Impeller: |
Single Suction Pump |
Product Description
Application
Applied to pumping such liquid which is clean,no solid matter or frictional low viscous,noncorrosive,non-crystallizable chemically neytral and close to water.Such as:
1.Tank filling
2.Domestic water supply
3.water transfer
4.Pressure boosting
5.Irrigation
Features
1.100% copper wire,and automatic wiring
2.Cold-rolled silicon steel sheet,with high-speed punching improve the efficiency and precision
3.Demagnetization of stainless steel nuts
4.Anti-rust treatment castings and electrophoresis
5.New testing equipment
| MODEL | INLET/OUTLET(mm) | MAX FLOW(L/min) | MAX HEAD(m) | MAX.SUCT(m) | RATED POWER(KW) | G.W
(kg) | PACKING DIMENSION(MM) |
| LHm/5C | 1 1/2"*1 1/2" | 500 | 12.5 | 8 | 0.6 | 14.8 | 250*205*270 |
| LHm/5B | 1 1/2"*1 1/2" | 600 | 13.7 | 8 | 0.75 | 15.7 | 250*205*270 |
| LHm/5A | 2"*2" | 650 | 14.5 | 8 | 1.1 | 16.3 | 250*205*270 |
| LHm/5AM | 2"*2" | 600 | 22.5 | 8 | 1.5 | 22.5 | 415*250*294 |
| LHm-6C | 3"*3" | 1100 | 12 | 8 | 1.1 | 25 | 455*260*230 |
| LHm-6B | 3"*3" | 1200 | 17.4 | 8 | 1.5 | 30 | 455*260*230 |
| LHm-6A | 4"*4" | 1200 | 18.5 | 8 | 2.2 | 37.5 | 475*260*335 |
| LCm130 | 1"*1" | 90 | 23 | 8 | 0.37 | 9.2 | 298*178*225 |
| LCm146 | 1"*1" | 90 | 28 | 8 | 0.6 | 12 | 335*213*274 |
| LCm150 | 1"*1" | 130 | 29 | 8 | 0.75 | 12.5 | 335*213*274 |
| LCm158 | 1"*1" | 100 | 36 | 8 | 0.75 | 13 | 335*213*274 |
| LCm170 | 1"*1" | 130 | 41 | 8 | 1.1 | 20.1 | 375*225*267 |
| LCm170M | 1"*1" | 170 | 36 | 8 | 1.1 | 22 | 375*225*267 |
| LCm190 | 1"*1" | 150 | 50 | 8 | 1.5 | 33.6 | 390*250*300 |
| LCm200 | 1"*1" | 160 | 58 | 8 | 2.2 | 38 | 390*250*300 |
Shanghai INFO Industrial Co. Ltd is a leading enterprises specialized in manufacturing various kinds of water pumps. Our main products including: Circulation pumps, Vortex pumps, centrifugal pumps, multistage pumps, Self-priming pumps, Garden pumps, Deep well pumps, etc.
History: More than 20 years professional manufacturer of water pumps
Scale: 6 production base in Zhejiang, have more than 1000 employees.
Production Marketing: Covering more than 60 countries and areas around the world.
Capacity: About 2 million PCS per year.
Certificates: CE, GS, RoHS, KS, etc.
