| Prod Model: |
GJQ(X)-DF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Concentric Reducer Flexible Rubber Expansion Joint |
| Brand: |
Liwei |
| Connection: |
Female |
| Standard: |
ANSI or According to Customer Demand |
| Material: |
Rubber |
Product Description
SPECIFICATIONS:
1. Qualified Joint Supplier in Nuclear Power Plant
2. China National Standards Drafting Unit of Rubber Joint
3.24 Years Experience
4. Easy Installation
5. ISO9001&ISO14001
Product Features:
(1) Economy: Compared with the systems of mechanic stretching and material damping, it has the advantages of little space covering, light weight, easy assembly and disassembly, labor saving and low cost. Its smooth inner wall can reduce flow resistance. It has good water tightness, so there is no need of gasket during the installation. It has wide application, large temperature-resistance scope and long working life. (This product can be used for 20 years if it is used indoors. )
(2) Displacement: Flange is free from pipe decentraction and imbalance. Its good flexibility allows compression, extension, distortion, deflection of vertical displacement, etc. Which can prevent the pipeline from damage of deformation and foundation settlement arising from expansion caused by heat and contraction caused by cold.
(3) Shock and noise absorption: The large damping of rubber sphere can effectively buffer and isolate vibration, control and reduce mechanical vibration, and absorb fluid impact noise. The reasonable installation between vibrating machine and metal pipe can decrease structure-borne noise by 15-25 decibels.
(4) Pressure resistance: The multilayered sphere structure can especially endure internal pressure, withstand strong blasting force and impact, and prevent deformation from external pressure. There are many pressure standards on work piece.
(5) Reducibility: After external force compressed, it can recover to original state when this force is removed.
(6) Wide application: Different rubber material and formula can make product possess different resistance to heat, oil, corrosion, age, abrasion and ozone.
Classification
(1) According to appearance: Concentric with diameter rubber joint, concentric reducer rubber joint, eccentric reducer rubber joint.
(2) According to the structure: Single ball flexible rubber joint, Double sphere rubber joint, spheres rubber joint, elbow sphere rubber joint.
(3) According to link the form: Flange coupling, Threaded joint
(4) According to working Pressure: 0.25MPa, 0.6MPa, 1.0MPa, 1.6MPa, 2.5MPa, 6.4MPa
Application Range
Equipped with the excellent comprehensive performances of flexible rubber joint, the product can be used for lift and transportation of raw water and sewage, transportation of water supply, cooling cycle water of thermal power plant, condensate water of metallurgy industry and chemical materials of chemical industries, cooling and dilution of oil and chemical industries and flexible connection of other industries. It is also suitable to transport all grain and powder material and gas for its high abrasive resistance.
Packaging & Delivery
Packaging Details: Unfumigation wooden case (Out package) and Plastic film and Textile membrane(inside package). We can make change as your request.
Delivery Detail: 7-40 according to the amount you booked
NOTES: IF OTHER STANDARD REQUIREMENT OR SPECIAL FLANGE NEED PARTICULARLY CUSTOMER MADE, PLEASE PROVIDE WRITTEN DRAWING, STANDARD, DATA, WE CAN MAKE CUSTOMER-MADE FOR YOU.
Contact us ;
Janice Chen
Mobile:+86-18039639133
Henan Liwei Industry Co. Ltd, established in 1983, is a leading manufacturer specializing in processing various steam, water, wind pipe expansion joints and compensation joints, and a main base for producing crushers and superfine grinding mills.
Liwei is the appointed enterprise by the former chemical industry ministry, national construction ministry and general petrol chemical company, member unit of China Water Supply Association and Power Equipment Network Union, and joints production unit recommended by China Water Association and National Metallurgy Ministry.
Based on the scientific management mode of modern enterprises, the company owns advanced process, strong technical strength, leading production equipment and complete testing instruments and apparatus, and it has 5 senior engineers, 16 engineers, 30 senior technicians and about 300 employees. With a set of effective service system, the company has formed a service team characterized of honesty and credit, planned site for clients free of charge as well as design and installation of foundation drawings and flow drawings. It can provide professional technical training, dispatch technicians for installation and commissioning in suit.
VTM Series Grinding Mill is the new product of Liwei in 2005, which have been granted certificates of national invention patent and utility model patent (Patent No.: ZL200510017387.2). The superfine vertical roller-based mill was developed and produced by Lu Fucai, a famous mill expert at home, professor Xu Changbai from Zhengzhou University and our company, and it is popular among users after it is put into practice. The mill is an original product with power on the grinding head which borrows advanced technologies at home and abroad. It has characteristics of low vibration, low noise, low energy consumption and high output, etc.
Liwei company has been equipped with rich technical strength, excellent design and complete products test measures. We also own a set of strict management system and high-quality technicians. In 2004, we have gained ISO9001 and ISO14001 certificate.
Insisting on the rennet "Development Through Technology, Making More Friends, Creating Green Environment and Responsible For Future", the company has been devoting itself to creating top products and well serving all clients around the world.
