| Prod Model: |
no |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Welding Line Type: |
ERW |
| Thickness: |
0.15-0.4mm |
| Outer Diameter: |
10-62.5mm |
| Braided Wire Material: |
Ss304 |
| Braided Mesh Layer: |
Single or Double Layer |
| Max.Working Pressure: |
12.5mpa |
| Working Temperature: |
-200~+600c |
| Connect Type: |
Male,Female Thread |
| Thread Standard: |
Bsp,NPT |
| Connection: |
Screw |
| Type: |
Horizontal |
| Material: |
Stainless Steel |
| Customized: |
Customized |
| Certification: |
ISO9001 |
| Warranty: |
12 Months |
| Application: |
Metallurgy |
Product Description
Stainless Steel Flexible Metal Hose
Stainless steel flexible hose is woven from stainless steel bellows, one or more layers steel wire or strip net at both ends with a connector or flange head for flexible components to transport all kinds of media.
Features:
Corrosion resistance, high temperature, low temperature (-196 ° C to +420 ° C), light weight, small size and softness. Widely used in aviation, aerospace, petroleum, chemical industry, metallurgy, electricity, paper, wood, textile, construction, pharmaceutical, food, tobacco, transportation and other industries.
1. Conveying corrosive chemical media or organic solvents. (For example: Handling ammonia, acetone, etc. )
2. Conveying high temperature gas, hot oil, high temperature media. (For example: Hot steam, thermal oil, etc. )
3. Conveying low or ultra-low temperature media. (For example: Liquid nitrogen).
4. Conveying water, gas, oil, media, high temperature environment. (For example: The water vapor in the coke making, steel making, continuous casting equipment, systems and hydraulic systems)
5. Damping or eliminating the noise of the pipeline. (For example: Import and export of the pump)
Application:
Stainless steel hose is used as a flexible pressure pipe installed in the liquid delivery system to compensate for pipe or machine, the device is connected end mutual displacement to absorb vibration energy can play the role of damping, silencers, with good flexibilitylight weight, corrosion resistance, anti-fatigue resistance, high temperature and many other a bit.
Stainless steel hose, use of imported SUS304 (0Cr18Ni9) SUS316 (0Cr17Ni12Mo2) and SUS316L (00Cr17Ni14Mo2) materials. The stainless steel wire braided hose, fluid transport metal bellows, stainless steel pump with damping hose, stainless steel fire hose, stainless steel bellows compensator, gas, mechanical stainless steel bellows.
The product has good flexibility, corrosion resistance, fatigue resistance, high temperature, noise damping, sealing and long service life, etc...Widely used in textile, chemical fiber, printing and dyeing, petroleum, chemical, steel, gas, air conditioning, automotive, fire fighting, urban water supply, construction, metallurgy, petrochemical, and other fields. The Stainless Steel Flexible Metal Hose
Nominal
Diameter
DN
| Ripple
Qty.
| Working Pressure(bar)
| Effective
area
(cm2)
| Max.
Outside
Diameter
(mm)
| Supplied Length (mm)
|
| 10 | 16 | 25 | 10 | 16 | 25 |
Axial Compensation (mm)
| Force Compress (N/mm) | Flanged End
| Welded End
|
| 32 | 8 | 20 | 18 | 15 | 26 | 63 | 98 | 16 | 225 | 160 | 250 | 264 | 280 |
| 40 | 8 | 20 | 18 | 15 | 44 | 89 | 106 | 23 | 244 | 164 | 259 | 269 | 289 |
| 50 | 8 | 20 | 18 | 15 | 70 | 70 | 138 | 37 | 259 | 172 | 276 | 282 | 306 |
| 65 | 8 | 26 | 22 | 19 | 44 | 55 | 68 | 55 | 270 | 215 | 294 | 300 | 322 |
| 80 | 8 | 34 | 28 | 25 | 33 | 41 | 54 | 81 | 284 | 240 | 338 | 344 | 366 |
| 100 | 6 | 40 | 35 | 29 | 75 | 93 | 117 | 121 | 304 | 235 | 317 | 323 | 345 |
| 125 | 5 | 38 | 34 | 29 | 59 | 74 | 92 | 180 | 334 | 282 | 314 | 316 | 342 |
| 150 | 5 | 40 | 34 | 29 | 62 | 78 | 97 | 257 | 364 | 282 | 339 | 338 | 367 |
| 200 | 4 | 42 | 38 | 34 | 68 | 78 | 111 | 479 | 442 | 280 | 348 | 348 | 372 |
| 250 | 4 | 59 | 52 | 47 | 42 | 45 | 55 | 769 | 507 | 315 | 379 | 415 | 379 |
| 300 | 4 | 59 | 52 | 47 | 59 | 65 | 71 | 1105 | 562 | 366 | 427 | 466 | 467 |
