| Prod Model: |
YXS-134/YXS-118 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material Type: |
Steel Strip |
| Roller Material: |
No. 45 Steel |
| Guaranteed Quality: |
CE Certificate |
| Type: |
Metal Rolling&Drawing Machine |
Product Description
Curving pipe forming machine is the complementary equipment which can be used to curve and neck down the pipe. The whole machine adopts the cam control to actualize automatic produce. The angle can be adjusted manually.
Flow chart:
Decoiling------guiding and feeding------cropping------roll forming------cut to length------run out table.
A. Main technical parameters
1. Item: YXS-134/YXS-118
2. Down pipe section specification(mm): 134 x 93/ 118 x 89
3. Material: Type Color steel sheet
4. Thickness (mm): 0.45-0.55.
5. Yield stress (Mpa): 230-300
6. Forming speed (m/min): 10
7. Roller material: 45# steel with chrome
8. Roller driven type: Chain transmission
9. Controller: PLC
10. Operation: Touch screen and button.
B. Components
This machine is composed of feeding device, main forming machine, forming cutter, PLC control system, hydraulic station, and out-put table.
C. Process Chart
Passive feeding---Guiding feeding---Roll forming---Cut to length---Out-put
D. Warranty, Year warranty
During the warranty period, maintain and change the spare parts for the customers for free (except for the instrument damage caused by human factors or natural disasters. ) And provide technical support for life-long
We make and design roll forming machine according to customer's request. Our machines have passed CE, Guaranteed quality.
