| Prod Model: |
WF-JF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Item: |
Custom Stainless Steel Casting Centrifugal Pum |
| Raw Material: |
Carbon Steel,Stainless Steel |
| Technics: |
Sand Casting+CNC Machining |
| Model Number: |
OEM Pump Impeller |
| Brand Name: |
Shengao,OEM |
| Toerance: |
+-0.5mm |
| Testing: |
Magnetic, Particle Inspector CMM |
| Weight: |
5-90kgs |
| Performance: |
Explosion-Proof Pumps |
| Export Markets: |
Global |
| Impeller Number: |
Single-Stage Pump |
| Working Pressure: |
Low Pressure Pump |
| Influent Type Of Impeller: |
Double-Suction Pump |
| Position Of Pump Shaft: |
Vertical Pump |
Product Description
Custom Stainless Steel Casting Centrifugal Pump Impeller
Application:
Widely used in motorboats, boats, pumps, etc.
Outside material:
Natural rubber, nitrile rubber, neoprene, silicone rubber, fluorine rubber,
Internal material:
Copper, fiber-based
Internal gear:
The product is due to the different axis types, is divided into many different gears Model:
Roughly: flowers tooth, shaped, semi-circular opening type, etc.
Product Features:
Oil, acid and alkali-resistant, water-resistant, wear-resistant
1. Investment casting sand casting/ lost wax casting/precision casting/gravity casting/stainless steel casting/carbon steel casting/ die casting/cookware handle casting/pan handle casting/home hardware casting;
2. Materials: Carbon steel, stainless steel, alloy steel and duplex steel, wcc, wcb, lcc, color metal etc;
3. Surface treatment: Heat treatment, machining, polishing, anodizing, hard anodizing, galvanized, enp, chrome plating, powder coating and painting;
4. Software for specification drawings: Pdf, auto CAD, solid work, proe;
5. Main production equipments: Wax injection, CNC-machine, heat treatment furnace;
6. Quality assurance in accordance with ISO9001: 2008, strict material inspection and exact dimension control, 100% quality control.
7. OEM order is welcome;
8. The parts can be made completely based on your specifications such as drawing, design, sample etc.
9. Export Markets: Australia Investment Casting / Precision Casting, America, United States. U. S. A. Investment Casting / Precision Casting, Canada Investment Casting / Precision Casting; U. K. England, Britain Investment Casting / Precision Casting, Germany
please submit as much of the below information as possible:
1. Pls provide complete 2D drawings of raw castings or finished parts,which should be clearly marked: part material,tolerances,heat treatment,surface treatment requiremnts;Point out the machining datum, key dimensions tolerance & important surfaces that need to pay particular attention to.
2. 3D drawings and samples are very necessary and helpfull for our quoting.
3. Testing and inspecting of the project & reporting requirements.
4. Order size and annual demand.
5. The requirements of process, packing and delivery.
6. FOB, CIF or EXW
Process |
| Material |
| Investment casting | Solidium Silcone(water glas) | Stainless Steel, Carbon Steel, Special Alloy Steel Bronze, Brass |
| Silica Sol |
|
| Sand casting | Green Sand | Grey Iron, Ductile Iron, Malleable Iron, Stanless Steel, Carbon, Steel, Brass, Bronze
|
| Resin Sand |
| Forging | Hammer Forging | Stainless Steel, Carbon Steel, Alloy Streel, Brass |
| Die Forging |
| Roll Forging |
| Machining | CNC Lathe,CNC cutting | All material |
| Stamping | Stamping | All material |
| Item |
| Material | Technical Process |
| 1 | Ductile iron
castings | ASTM A 536-Gr.60-40-18,65-45-12,80-55-06,80-60-03;
DIN-GGG40,GGG50,GGG60,GGG70;
JIS-FCD40,FCD50,FCD60,FCD70;
BS-Gr370-17,Gr420-12,Gr500-7,Gr600-3,Gr700-2;
NF-FGS370-12,FGS400-12,FGS500-7,FGS600-3,FGS700-2; | Green-sand moulding
Resin-sand moulding
Lost foam cast
Shell-core cast
Electric-furnace smelting |
| 2 | Grey iron
castings | ASTM A48-No.20,25,30,35,40,45,50;
ASTM A126-Class A, Class B, Class C;
DIN-GG10,GG15,GG20,GG25,GG30,GG35;
JIS-FC10,FC15,FC20,FC25,FC30,FC35;
BS-Grade 150,180,220,260,300,350;
NF-FGL150,FGL200,FGL250,FGL300,FGL350; | Green-sand moulding
Resin-sand moulding
Lost foam cast
Shell-core cast
Electric-furnace smelting |
| 3 | Carbon steel
castings | ASTM A216-Gr. WCB, Gr. WCA, Gr. WCC;
ASTM-415-205, 450-240, 485-275, 80-40;
DIN- GS-C25(1.0619), GS-38(1.0416),
GS-45(1.0446), GS-52(1.0552), GS-60(1.0558);
JIS-SC410, SC450, SC480, SCC5;
BS-A1, A2, A5;
NF-GE230, GE280, GE320, GE370 | Soluble glass sand moulding
Resin-sand moulding
Lost wax casting
(Investment casting)
Lost foam cast
Shell-core cast
Electric-furnace smelting |
| 4 | Stainless steel
castings | ASTM-CF-8M, CF-8, CA-15, CA-40, 316, 304;
DIN-G-X6CrNi18 9(1.4308), G-X7Cr13(1.4001)
G-X20Cr14(1.4027), 1.4408;
JIS-SCS13, SCS 1, SCS 2, SCS 14A;
BS-304C15, 410C21, 420C29, 316, 304;
NF-Z6CND18.12M, Z6CN18.10M, Z12C13M, Z20C13M | Soluble glass sand moulding
Resin-sand moulding
Lost wax casting
(Investment casting)
Electric-furnace smelting |
| 5 | Alloy steel
castings | DIN-GS-40Mn5(1.1168), GS-20Mn5(1.1120);
GS-37MnSi5(1.5122), GS-34CrMo4(1.7220);
JIS-SCMn3, SCW480, SCSiMn2, SCCrM3, SCMnCR3;
ASTM-LCC
UNS-J02505, J13048
NF-G20M6, G35CrMo4 | Soluble glass sand moulding
Resin-sand moulding
Lost wax casting
(Investment casting)
Electric-furnace smelting |
OUR SERVICE:
1. Working Hour:................7:00AM--10:00PM (Beijing Time)
0:00AM--3:00PM (European Time)
3:00PM--6:00AM (LA Time)
7:00PM--10:00AM (Toronto Time)
2. Working Days: ................7days a week, 365 days a year.
3.Feedback Time: ..............with in 12 hours
Quotation Time: ............. with in 48 hours
4.Lead Time:.......................mould 30~45days.
5. Manufacture schedule: . we report our production schedule to customers everyday by mail or photoes, it's just like the production is happened under your nose.
6. Speed delivery:............... The shipping date never late than settled. ( expect for force majeure.)
7. Quality control:.............. Both in-house QC and lab test provided. Test report along with delivery according to customer's request.
8. Weifang Shengao Machinery Co., Ltd. is a manufacturer who can provide you one stop solution for all metal products. We can provide you from designing to delivery.
WeiFang Shengao Machinery Co., Ltd is located in WeiFang the famous city in China and the world center of kites. It is 140 kilometers far away from Qingdao port, the transporation is very convenient. Our company use the location advantages of ShanDong province to integrate resources so that we can processing according to the drawings of customers. We mainly undertake the casting parts, machined parts and other products. Our Import and Export Department have many years experiences of foreign trade, products are mainly exported to the United States, Denmark, Italy, Russia, Australia etc.
Over the years, company adhere to the guideline for management of "Quality first, Reputation first, Delivery just-in-time, Price best". We will try our best to improve the technical level and perfect the enterprise management. Our company will depend on superior quality of products and sincere service to cooperate with dometic and overseas, new and old customers and establish eternal friendship to create a bright future.
