Prod Model: |
ML1200/ML1300/ML1400/ML1600 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Max.Rule Area: |
1200*820mm |
Placing Form Of Template: |
Horizontal |
Imprinting Type: |
Platen |
Die Cutting Tool: |
Metal Mold |
Automatic Grade: |
Automatic |
Application: |
Earthquake Products |
Product Description
Main features:
It adopts high quality material and high tension of casting. Four-shaft bevel wheel structure with steady operation, great cutting, low noise.
The operation height is reasonable, the open of frame is large
Electrical system is design according to IEC standard.
It has three functions for single slitting, successive slitting. Time delay, The scope can be adjusted.
Safety protection system is reliable. Concentrated lubricating system
Product Description:
It's kind of special equipment for all assortments of common card boards, corrugated boards, plastic sheets, leather products, It's suitable for printing, packing, decorating, plastic industries etc.
With the features of firm structure, exquisite making, great cutting. High precision, ease of operation, safety and reliability etc.
Features
· Sliding bearings are made of high quality alloy cooper, thus to get effect of anti-friction and shake reducing.
· High strength due to whole body casting with top quality material
· Smooth running, high pressure and low noise with 3-step helical gear mechanism
· Flywheel is with big moment of force and heavy pressure.
· High strength due to one piece casting by using top-ranking material for machine frame.
· Single plate electromagnetic clutch is sensitive and reliable.
· With functions of single, continuous and opening dwell operation, dwell range is adjustable.
· Operating position is reasonably arranged, moving-bed can be opened to its optimum.
· Safety protection system is reliable
· With concentrated lubricating system.
· Adjustable chases
· Connecting rod adopts 45# carbon steel with high strength.
· platform is made of hard enough stainless steel
Model | max.rule area | Working speed | Max.rule length | Motor power | Weight | Overal dimension |
ML3000 | 3000*1650mm | 13+/-2(stokes/min) | <100m | 30kw | 28000kg | 2900*3750*2600mm |
ML2500 | 2500*1400mm | 13+/-2(stokes/min) | <75m | 18.5kw | 19000kg | 2300*3600*2150mm |
ML2000 | 2000*1400mm | 16+/-2(stokes/min) | <58m | 15kw | 15500kg | 2270*3100*2150mm |
ML1800A | 1800*1400mm | 16+/-2(stokes/min) | <52m | 15kw | 14800kg | 2240*2800*2130mm |
ML1800 | 1800*1280mm | 16+/-2(stokes/min) | <50m | 11kw | 13000kg | 2180*2760*2100mm |
ML1600 | 1600*1250mm | 16+/-2(stokes/min) | <43m | 11kw | 11800kg | 2170*2560*2080mm |
ML1500 | 1500*1100mm | 17+/-2(stokes/min) | <40m | 7.5kw | 8300kg | 2010*2480*1960mm |
ML1400 | 1400*1000mm | 17+/-2(stokes/min) | <38m | 7.5kw | 7200kg | 2010*2400*1950mm |
ML1300 | 1300*920mm | 18+/-2(stokes/min) | <38m | 7.5kw | 6000kg | 2000*2140*1940mm |
ML1200 | 1200*850mm | 18+/-2(stokes/min) | <32m | 5.5kw | 4800kg | 1950*1950*1930mm |
ML1100 | 1100*800mm | 20+/-2(stokes/min) | <30m | 5.5kw | 4200kg | 1900*1780*1700mm |
ML1040 | 1040*720mm | 21+/-2(stokes/min) | <30m | 5.5kw | 3900kg | 1800*1680*1660mm |
PYQ203D | 930*670mm | 23+/-2(stokes/min) | <25m | 4kw | 3000kg | 1670*1670*1630mm |
ML750 | 750*520mm | 25+/-2(stokes/min) | <15m | 2.2kw | 1900kg | 1260*1400*1280mm |
Our Company are not only Trading Company but also manufacturer factories.
We have our own machinery factory(LIZHONG) And Our Own Zipper&Slider factory.
Our Machinery facatory professionally makes the various disposable paper container making machines and products such as: Paper cup machine, Double wall paper cup machine, Paper plate/dish machine, Paper lunch box machine, Paper cake tray machine ect. We also make Cup Packing machines and Die Cutting machines.
Since company was founded, facing the fierce competitive market, we persist in the business idea of 'First Quality, Credit Orientation', carry out the enterprice internal management, make importance of sic-tech and information development to have the 'LIZHONG ' brand machines to win the market. The products are well distributed to more than 20 provinces and areas at home, and exported to many countries such As USA, UAE, Russia, Jordan, Syria, Pakistan. Israel, Palestine, Ukraine, Egypt, Algeria, Iran, INDA, South Africaect all over the world. The reliable products have won wide acceptance with first-class quality and perfect after-sales service at home and abroad.
Welcome to visit our Company and We are very willing to cooperate with the national and overseas customers to achieve brilliant achievement together.
