| Prod Model: |
UL+Z-1800+255/4+8 |
| Markets: |
North America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Copper Rod Continuous Casting And Rollin: |
4+8 Type |
| Raw Material: |
Copper Scrap |
| Model: |
255/4+8 Type |
| Final Product Dia.: |
8mm Copper Rod |
Product Description
Five-wheel type continuous casting machine is composed of crystallizing wheel, pressing pulley, tension pulley, guiding wheel, casting ladle, cooling device, steel belt drying device, dust removing and carbon coating device, ingot-picking up device, pulling machine, throttle, pneumatic control system and so on. (The extra automatic casting system can be equipped according to user's requirement).
The five-wheel continuous casting machine is produced by the patent technique(Patent No.: ZL00244512.3), which, on one hand, protects casting bars coming from the casting machine from meeting steel belts, so that the bars can be sent into the rolling mill directly without reversing the angles. On the other hand, the crystallizing wheel is of "H" shape, and the cooling methods include controllable inner cooling, outer cooling, side cooling and partly water cooling, and stainless steel is adopted in all the methods. The adjusting valve is equipped respectively in order to automatically control the water flow while casting. The big cooling section and good cooling effect ensure the crystal of smelted copper close and equal while being cast. The five-wheel continuous casting machine has five wheels on the same plane, which is convenient for installation. Level casting can make smelted copper flow to the crystallizing wheel smoothly. There are two casting ladles, and the upper one controls the flow to be cast to the small lower one. The pneumatic steel belt tensioning and mechanical pressing are adopted to ensure the continuously adjustable tension and pressure.
Supplier intructs user to do installation, and do commissioning.
| 1 |
casting machine | ()
Crystallizing wheel (including transmission device and inner cooling system) |
| (2) Pressing device (including 2 rollers) |
| Tension device |
| ()Outer cooling device (including side cooling) |
| Ingot picker |
| Guiding bridge |
| ()Casting ladle (only supply the outer casing) |
| Main motor |
| Steel belt |
| 2 |
Auxilliary devices | ()Pulling device (incluing pneumatic device) |
| Automatic shearer |
| ()Straightener and angle shaver(including pneumatic device) |
| () Casting bar brushing machine (including pneumatic device) |
| () Material feeding device (including pneumatic device) |
| 3 |
Continuous rolling machine | 4(2)two rollers type rolling stand 4 pieces (2 for each) |
| Y8(4)three rollers Y type rolling stand 8 pieces (4 for up transmission stands, 4 for lower transmission stands) |
| (,)Lubricating oil system (including cooling, and filter) |
| (,) Emulsion system (including cooling, and filter) |
| Rolling machine main motor |
| 4 |
Electrical control part | Relay control cabinet |
| Power supply switch cabinet |
| Rolling machine transmission cabinet |
| Main machine operating platform |
| Take-up device operationg platform |
| , Instruction book for frequency converter and DC speed regulator |
| 5 |
Take-up device | , Copper rod cooling and reverting and drying device |
| Pulling wheel |
| Take-up speed reducing box |
| Head laying device |
| ()Take-up device (including dule-direction moving trolley and track) |
We, Deyang Dongfang Zhuoyue Electrotechnical Equipment Co., Ltd are located in Deyang of China, the major technology and equipment manufacturing base. Now, our manufacturing factory building covers an area of more than 10, 000 square meters. We have more than 100 sets of large and medium-sized processing and manufacturing equipment, and a well-trained design, marketing, managing, machinery processing and equipping team composed of nearly 200 people.
We can manufacture various of complete plant(the latest model in domestic market), such as, Aluminium&Alloy Rod Continuous Casting And Rolling Line, Copper Rod Continuous Casting and Rolling Line, Tubular Stranding Machine, Rigid Frame Stranding Machine, Continuous Lead Extruding Line, Straight-line Aluminium &Alloy Rod Breakdown Machine, Straight-line Copper Rod Breakdown Machine, etc.
We have strong production ability and excellent sales team, we sell our products to our user directly, also, we always sell our products by some trading company or middle trader. We exported so many products to other countries such as Kazakhstan, Indonesia, India, Thailand, Korea, Ukraine, Mexico, Brazzil, Vietnam, Argentina, Kenya and so on.
We would like to provide the high-quality products and the good service, meanwhile, we will quote you the lowest market price.
We will be together with all the staff and workers, wholeheartedly offer our service, wait for your presence and stride forward with you hand in hand towards a brighter future.
