| Prod Model: |
LM-LOU |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Roll Forming Machine |
Product Description
Material: Galvanized sheet or colored armor plate
Equipment operation Automatically
Voltage AC380/50-60Hz
Number of roller 13--15
Thickness of sheet(mm) 2.0---3.0
Material width(mm) According to the products spec
Formed width(mm) 750mm
Productivity 0-15m/min
Output /shift (8hs) 5000m
Producing capability 5000 m2/8hs
Diameter of shaft 80mm--100mm
Dimension of main structure(mm) 15000mm*1700mm*1400mm
Material of rollers 45# steel
Weight 5130 kg
Total power(kw) 11+11+5.5 kw
Driven system Single
Power of hydraulic system 5.5 KW
Power of main molding core 11kw+11KW(cycloidal planetary gear speed reducer).
Liming Stamping Form Machine Manufactured Co., is a leading manufacturer for steel plate coiling machinery, roll-forming and automatic production lines. The products are mainly used in steel structure industry for producing C&Z shape purlin, load-bearing plate of buildings, wall and roof protective structure colorful steel plate, thermal insulation; Colorful decorating and protecting steel plates for high-grade steel structure residences; Environment industry anode plate and kathode plate lines for removing dust; Traffic-transport industry freeway guardrail plate, vehicle roll-forming materials; Logistics. Goods shelf pillar, holding beam; Cable bridge, Cabinet pillar and others collorary thin wall roll-forming materials serials-such as goods shelf board, kinds of cabinet screen plate. Then, it can also supply kinds of line of uncoiler, leveler, slitting recoiler, cut-to-length shear stacker.
Liming has advanced production equipment. Engineering personnel and technicians of Bohai are rich in experience of designing, developing, and manufacturing of machineries, They pay close attention to and keep up with the developing trend of technologies and adopt new technologies in the manufacturing of our machinery products, to keep them competitiveness. The products are characteristic of high efficiency, high flexibility and low production cost.
