| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Roll Forming Machine |
Product Description
Rolling speed: 5-8m/min
Roll station: 13 steps.
Raw Materials: 1250mm.
Thickness of Material: 0.3-0.8mm.
Roller's material: 45# high quality steel with surface coated with hard chrome 0.05mm.
Shaft material: 45# high-quality steel.
Shaft diameter: φ 75mm.
Thickness of Siding Plate: 18mm.
Ladder Step: Hydraulic control, after molding then cut ladder-shape outage.
Cutting method: Hydraulic control, after molding then cut it outage.
Cutting Material: Cr12MOV, hardening HRC58-62
Chain wheel: Track distance 25.4; Number of wheel teeth: 18
Stander: Welding by 350*175H steeSquare box: Material Q235-A wallboard-type square box
Main engine power: 5.5KW
Working pressure of hydraulic system: 16MP
Motor power of hydraulic system: 4KW
Electric controlling system: PLC system.
Cutting deviation: 10M± 2mm
The machine size(L*W*H): 8500mm*1500mm*1300mm
1. The structure is simple, the outlook is artisticbecause the complete machine uses the section structure, after welding whole processing, therefore structure succinct reasonable, saves carries ability steadily, the revolution is reliable.
2. After the equipment roller wheel uses the high quality No. 45 forging steel precise manufacture, after coating the hard chromium on the surface, achieved the roller skin hardness is high, smooth, plate formation surface non-damage effect.
3. The stone roller is No. 45 steel after the quenching and retempering treatment, enhances the bearing the intensity, synthesis mechanical properties and so on degree of hardness
4. All of main primary device in electricity control system are imported from Mitsubishi Japan.
5. Uses the completely automatic cut-length-off, the fixed-length localization is precise, shape of strip from beginning to end is artistic neat.
6. Low noisy, high efficiency
7. Installation and Training Service Provided
8. CE Approved.
9. 14-month warranty.
Weifang Highfull Machinery Co., Ltd is located in Weifang City, the kite capital, Shandong Province, conveniently located near Qingdao City's sea and air port, Jiqing expressways and Jiaoji railways.
Rely on the good foundation of culture and machinery, as well as our fine product quality, perfect services, we win the market and make rapid progress.
We are a high-tech enterprise of producing the steel plate cold roll forming machine, mainly dealing with Mainwhile, we are able to produce and design the cold roll forming machine according to our customers' specific requirements. With our strong technical force, in the factory, there are more than 60 sets, such as milling machine, planing machine, grinding machine, drilling machine, planer type milling machine, heat-treated furnace and so on. We have 30 high-ranking technicians and engineers or so. The main products includes, roller press, roll bending, forming machine, lever device, slitting machine, color steel tile equipment, C/Z shaped steel equipment, steel structure equipment, colored sheet door equipment, color section equipment, security door equipment, security door frame equipment, square and round steel tube equipment, door frame section, auto car carriage plate equipment, motorized tricycles carriage plate equipment, electrocar carriage plate equipment, container equipment, car sections, stainless steel door equipment, fire door equipment, light steel keel equipment, garage door equipment, solar energy stand equipment, goods shelf section equipment, bridge bus duct equipment, high-speed guardrail equipment, and all kinds of roll mill, roller etc. Cold bending roll forming machine.
Our company pursues progress continuous on the way to technological innovation in recent years. We set up R&D(research and development)center in Shanghai in 2006. We have developed ultrasonic sections, eddy currents etc. Nondestructive testing equipment united with Shanghai Jiaotong University and Shanghai Ligong University etc. Research institutions. We cooperate with friends of home and abroad.
