| Prod Model: |
ALKY-80T |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Working Pressure: |
80t |
| Working Material: |
Metal Sheet |
| Power Supply: |
380V or Optional |
| Mould: |
Customized |
| Forging Forming Method: |
Mold Forging |
Product Description
H frame hydraulic deep drawing press
European Technology Cooperation, Building Top Quality.
Features:
The hydraulic deep drawing press is a specially designed machine in high accuracy and excellent performance, for deep drawing and forming metal plates.
According to the requirement of current production speed and machine safety, the press adopts special loop to reach both.
1. Safe and precise control systems are easy to handle and work with great effiency.
2. Systemized hydraulic unit is designed of leak-prevention, anti-vibration and easy-maintenance.
3. Each hydraulic press is manufactured under strict quality control process to assure the best performance and accuracy.
Applications:
Deep draw press is applied in production techniques, like deep drawing, stamping, cutting, bending, flanging of metal sheet.
Particularly applied in the following industries:
1) Automobile Industry: steel ring, vehicle body, chasis, axle housing, fuel tank, door, wheelbarrow tray and more.
2) Household Appliance Industry: components for air conditioner, refrigerator, washing machine, microwave oven, electric cooker etc.
3) Kitchen Ware Industry: stainless steel utensil, LPG cylinder, cooking bench, etc.
4) Aluminum Cookware.
Options:
Digital Control, Common Control;
Slow Speed, Medium Speed, Fast Speed;
Water Cooler, Air Cooler, Forced Chiller;
Die Change/Die Clamp Device;
Interval Lubrication, Cycle Lubrication;
Upper Ejector, Bottom Ejector;
Right/Left Stamping Damper Cylinders.
| Technical parameter/Model | Type | ALKY- 25 | ALKY-40 | ALK27Y-50 | ALKY-63 | ALKY-80 | ALKY-100 | ALKY-125 |
| Nominal presssure | kN | 250 | 400 | 500 | 630 | 800 | 1000 | 1250 |
| Max.work pressure of liquid | MPa | 22 | 21 | 21 | 20 | 21.5 | 22.5 | 25 |
| Slipper max.sroker | mm | 130 | 130 | 130 | 150 | 180 | 180 | 220 |
| Slipper work times | 1/min | 10-15 | 10-50 | 10-50 | 10-40 | 10-40 | 10-40 | 10-30 |
| Max.closing height | mm | 315 | 320 | 320 | 445 | 470 | 470 | 520 |
| Stroke adjuster | mm | 130 | 130 | 130 | 150 | 180 | 180 | 220 |
| Throat depth | mm | 210 | 235 | 235 | 260 | 310 | 310 | 350 |
| Height from bench to ground | mm | 740 | 740 | 740 | 750 | 770 | 770 | 870 |
| Speed to quickly mone downwards | mm/s | 225 | 265 | 265 | 220 | 220 | 210 | 250 |
We are pleased to introduce ourselves as one of the professional manufacturer of Press Brake, Shearing machine, Rolling machine, Punch machine, CNC lathe, CNC machine center in China.
We also make the Tools for Press Brake, Blades for Shear Machine, Dies for Punch Machine.
AMADA, MURATA, TRUMF, STRIPPET, LVD, FIN POWER, JIN FANGYUAN, YANGLI, JIEMAI IN JINAN, TAILIFT
Our international brand is ALUKE MACHINE TOOL Co., Ltd
We have been working in the same field since 1982.
In the mean while we have Supplied a number of metal process machinery all over the world of all Capacities, model and all type of sheet metal machineries. We have qualified with CE mark, ISO 9002-ISO 2000.
We have satisfied customers throughout over world who gaves us repeated order due to very good sales, services and customers relationship.
Our Sales Net are: UK, USA, Italy, Romania, Russia, Ukraine, Brazil, Colombia, Peru, Venezuela, Ecuador, Paraguay, Chile, India, Pakistan, Singapore, Vietnam, Iran and so on, more than 50 countries.
If any of the items can reach your filed, please contact us freely, we are always at your service.
