Hky-688 Deck Roll Forming Machine

Hky-688 Deck Roll Forming Machine
Price: US $ 55000/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P
Prod Model: HKY-688
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Forging Forming Method: Mold Forging

Product Description

Deck floor roll forming machine, floor deck roll forming machine, floor deck forming machine

Technical Parameters
1. Main Motor Power: 15KW
2. Hydraulic Station Power: 5.5KW
3. Hydraulic Oil Pump: CB-E310
4. Sprocket: P-50.8
5. Roller Station: 16
6. Yield Strength: 32MPa
7. Diameter of Principal Axis: 95mm
8. Material of Roller: 45#steel hard chrome plating
9. Material of Blade: Cr12
10. Processing Speed: 8m/min
11. Thickness: 0.5-1.5mm
12. Installation Dimension (L*W*H): 9.5m*1.4m*1.4m
13. Equipment Parts: Forming machine, hydraulic cutter, hydraulic station, electric controlling system and counter.

The deck floor panels forming by this machine is used for building surface panels, it has many advantages, such as high wave, strong, high automation and low cost.

The panel formed by this machine is good profile design, height wave, strong. When make the installation, put it with the welding reinforced network and concrete scene watering combination, good adhesion. This machine products used in high building construction, it can save the steel panels and the floor loading weight in the same loading weight condition then save the investment cost

This machine is composed of un-coiler, feed leading table, main forming machine, punching system, cutting device, hydraulic station and computer control system.

Optional system are normal un-coiler and hydraulic un-coiler.


Jacky (sales manager)
Botou Huikeyuan Engineering Control Co., Ltd.
Tel: 86-317-7668238
Fax: 86-317-3087243
Mobile: 15503170286
Website: Www. Rollformingmachine-China. Net
Botou Huikeyuan Engineering Control Co., Ltd is the "Important individually-run enterprise"of Botou City. Since many years, we devoted ourselves to develop the metal-plate cold forming machine, now we have unique management pattern and products development ability. Our company leads first in the same field. Our products have light structure and reasonable design, they won praise from same steel structure field because of the innovation constantly.
The company is located at side of No. 104 national road in Botou City, which is the famous casting city in China. The company covers an area of over30, 000 square meters. We have near 100 technicians in different skills. We remain the first-rate level on design and production of C-type and Z-type steel equipment, at the same time, we increased the tile press computer control system production line, antique glazed tile machine production line, H-type steel machine production line, big-span, no-beam structure equipment production line and automobile carriage board machine production line. We can design and manufacture the special type machine according to the customer's requirement and we could provide technical guiding, production, installation, debugging and maintenance service to all customers.
According to the requirements of market, ou company produced new and high technological products-KDQ type quantified cutting control system in Jan. 2000. This control system has functions of measuring, monitoring and early warning. It has high starting point, accurate measurement, easy operating and complete monitoring. It is the originated one in domestic, a breakthrough of cutting control on microcomputer technique and the miracle of rutting fields.
At recent years, large of products were sold to Russia, India, England, Australia, America, Kazakhstan, Tajikistan, Malaysia, Nigeria, Rumania and Albania etc, more than 50 countries and regions. ur products won acclaim from all customers in domestic and abroad.
