| Prod Model: |
HCC 450x2 |
| Markets: |
South America,Southeast Asia,Africa,Mid East,Eastern Asia |
| Enter Attribute Here (e.g.: Size): |
Enter Value Here (e.g.: 12 Inches) |
| Casting Method: |
Special Casting |
| Casting Form Material: |
Graphite |
| Casting Metal: |
Nonferrous Alloys |
| Casting Form Usage Count: |
Disposable |
Product Description
Functional characteristics:
1. Holding temperature furnace adopt stepless pressure-regulator, the control of temperature is continuous and automatic
2. Holding temperature furnace adopt large-area jet-melt ditch.
3. Monolithic crystallizer is installed and replaced
4. The tractor is designed specially, center line is automatic adjustment.
| item | unit | parameter |
| mode | piece | 2,4,6 |
| material |
| lead brass, brass,copper,copper alloy |
| specification | mm | Φ20-Φ80;Φ120,Φ140,Φ180,Φ200 |
| speed | mm/min | 60-700 |
| power | KW | 550 |
| capacity | Kg/year | 6000t |
| max temperature |
| 1300 |
| range of temperature |
| ±10 |
| noise | decibel | ≤80 |
| weight | kg |
|
| dimension | mm |
|
Keda copper and equipment company was restructured in 2000 from it is specializing in equipment manufacture for copper and aluminum fabricating industry. It is engaged in designing, manufacturing, installing and commissioning of copper fabricating equipments.
Our main products are horizontal continuous casting machine (for copper and aluminum strip, copper tube, copper rod), (copper strip 200mm-650mm), up casting machine for copper tube, copper rod, copper busbar or flat, semi-continuous casting machine, continuous extrusion machine for copper rod, wire, aluminum tube.
Our technique team is very experienced in installation and commission, which can save customer's commission time and cost largely. We also have a very efficient after-market service team which is ready to resolve any related problems from our costumers.
