Product Description
Features:
Costumer design meet unique demands
Latest technology--IGBT inversion technology reduce operating cost
LC series circuit and voltage feedback design achieve energy saving
Energy saving up to 30% compared with SCR technology induction machine
Diode rectification technology make sure high power factor - never less 0.95
Soft switch technology ensure high efficiency up to 90%
Be started up 100% at any load, 100% continue duty
Power & frequency tracking automatically improve reliability of equipment
Prefect protection system enhance long-term performance
Integrated transformer with small size
Application:
Suitable for heating large heating part
Forging & forming
Heat treatment such as hardening, , tempering, annealing and etc.
Melting for aluminum, copper^
Pipe Pre-heating before welding and stress relieving coating and cure for post coating
Pipe Bending
Optional:
Temperature control system enhance heating precise
Automatic transmission
External cooling system--DI Water cooling system or chiller, enhance good reliability of induction machine.
| Power Output | 400KW |
| Oscillating Frequency | 0.5KHz--8KHz |
| Input Power capacity | 500KVA |
| Input Voltage | 380V/50Hz |
| Operation Voltage | 340V-430V |
| Input Current | 650A |
| Duty cycle | 100% |
| Cooling Water Flow | 25--35m3/h |
| Weight | 340kg |
| Dimension | 920X930X2080 |
Chengdu Duolin Electric Co., Ltd, is the first company in China to professional design and manufacture medium, high and ultrasonic frequency induction heating machine. Now our company is expanded to over 10, 000m2 modern production and two plants, more than 200 employees, forty branch offices all over China.
With annual throughput more than 5, 000 sets, our products are sold not only in China but also oversea such as India, Pakistan, Vietnam, Malaysia, Singapore, Russia, Australian, America, Romania, Bulgaria and South Africa, etc.
