| Prod Model: |
SF-120 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Used For: |
Forging, Hardening, Melting, Heating and etc. |
| Place Of Origin: |
Yongkang China (Mainland) |
| Work Power: |
380V 50-60Hz |
| Brand Name: |
Yuelon |
| Certificate: |
CE |
| Work Condiction: |
24hours |
| Cooling: |
Water |
| Guaranty: |
12months |
| System: |
IGBT |
| Duty Cycle: |
100% |
| Forging Forming Method: |
Mold Forging |
Product Description
Model: YUELON-120AB
Max output power: 120KW
Max input current: 240A
Frequency: 10-40kHz
Working voltage: 342-430V
Input voltage: 380V50Hz/60Hz
Duty cycle: 100%
Water flow: 68L/min
Generator weight: (0.1Mpa)
Transformer weight: 138KG
Generator size: 95KG
Water flow: 930*550*1190
Transformer size: 560*440*530
Application of Induction Heating Equipment:
A. Heating (hot forging, hot fitting and smelting):
1 Hot forging aims to fabricate the work pieces of certain temperature (different materials require different temperatures) into other shapes through forging press with the help of punch press, forging machine or other equipments, for instances, hot extrusion of watch case, watch flan, handle, mold accessory, kitchen and table ware, art ware, standard part, fastener, fabricated mechanical part, bronze lock, rivet, steel pin and pin.
2. Hot fitting refers to the connection of different metals or metals with nonmetals through the heating based on the principle of hot expansion or hot smelting, for instances, embedded welding of copper core of computer radiator with aluminum sheet and speaker web, compound of steel and plastic tube, sealing of aluminum foil (tooth paste peel), motor rotor and sealing of tubular electric heating element.
3. Smelting mainly aims to melt the metal into liquid by using the high temperature, which is mainly applicable to the smelting of iron, steel, copper, aluminum, zinc as well as various noble metals.
We are specialized in the researching and manufacturing of transistor type medium and high frequency induction heating machine and related equipments. Our company was established in 1998 and is privately held.
Precision induction heating solutions are our specialty. Use induction heating to improve the effiency and effectiveness of your industrial heating process. That are used for application such as brazing, heat treating, annealing, hardening, bonding, hot forging, melting, shrink fitting etc.
Our induction heating machines are available from 2kw to 750kw deliverable output power with 0.5kHz to 1.1MHz operating frequency range. And 100% solid state technology. All our products are divide into three major series according to the frequency:
Medium Frequency series (MF series)
High Frequency series (HF series)
Ultrahigh Frequency series (UF series)
Depend on our advanced technologies, reliable solutions and excellent after service, our induction heating machines are sell well at home and abroad.
Welcome to enquiry more information, any questions or technique support, please contact us via e-mail for details. Your satisfaction are our team's goal.
