(LGZ-1600+255/15Y) Type Aluminum Alloy Rod Continuous Casting and Rolling Machine
| Price: |
US $ 234426/Set |
| Trade Terms: |
FOB,CFR,EXW |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T |
| Prod Model: |
LGZ-1600+255/15Y type |
| Markets: |
Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| (Lgz-1600+255/15y) Type: |
Aluminium Alloy Rod Continuous Casting and Rolling |
Product Description
UL+Z-1600+255/15 aluminum and aluminum alloy rod continuous casting and rolling line Features,,,,.H,.,,,,,;,;,(),,,,,,,.,,,,,.The fourth generation aluminum rod continuous casting and rolling line optimized the equipment hardware, so that make sure the line runs long term and stably, reduces the running cost, has the advantages of economic, environmental protection and low carbon, and the produced rod has the best quality. The crystallizing wheel of the fourth generation casting machine adopts H type to strengthen the structure, which improves the life span of crystallizing wheel. Adopt drainage tube and horizontal casting to make the molten aluminum enter the crystallizing cavity stably, will not bring sinuous flow and turbulence, will prevent oxide film on the molten aluminum surface between the launder and middle ladle from being damaged, will lessen the re-inhale and re-oxidation of molten aluminum, so that improve the quality of aluminum rod. The fourth generation aluminum rod continuous casting and rolling line possesses the advantages of both aluminum alloy rod rolling machine and common aluminum rod rolling machine, improves the strengthen and the life span of easy-damaged parts; new type coiler adopts conic rolling wheel water drum type coiler system, which has no butter no scratch, no rod pile, which is economy, environmental protection and without pollution, also can be used to electrotechnical aluminum rod, varnished wire and extruded tube directly, especially for producing the aluminum and aluminum alloy rod. The production line can set linkage matching program on electric system in aspects of casting speed, rolling speed, pulling speed and rod collection speed. So that makes sure the synchronism of production line, fine tuning during operation, and the convenient and easy operation.1. Machine application,,,9.5mm,12mm,15mm.The line is designed to produce aluminum rod or aluminum alloy rod by means of continuous casting and rolling, the material is pure aluminum ingot, electrolytic molten aluminum or aluminum alloy, and the produced rod diameters are9.5mm,12mm and 15mm.2. Composition2.1 :UL+Z-1600+255/15 Equipment name: UL+Z-1600+255/15 type aluminum rod continuous casting and rolling line.2.2 :,,,,,,255/15,(),,,,.(:,,,.,) Main component: four-wheel type casting machine, active fore traction, automatic shearer, straightening device, frequency doubling induction heater, active feeding device, 255/15 aluminum alloy rod continuous rolling machine, conic pipe rolling wheel drum type rod guiding coiler (rod guiding without oil), orbital dual-basket rod collection, emulsion circulating device of rolling machine and electric control system of the line. (Remark: aluminum melting furnace, holding furnace and launder should be ordered separately, the outside cooling system and the cooling system of heater should be prepared by the users.)3. Brief technological process:
3.1,→()→→→→→→→→()→()→→→()→→→→→→. Aluminum ingot→ molten aluminum (aluminum alloy) → molten aluminum refining→ sampling→ holding device→ filting→ casting→ cooling casting blank→ sending ingot by active traction and front blank shearing→ (straightening) → (induction heating) → active feeding and enter the rolling→ rolling→ rod guiding without oil (quenching cooling) →continuous rod winding→orbital dual-basket rod collection→bundle→finished aluminum rod measuring→check up→warehousing.3.2,(),,2450mm2.,(),,,. The melting aluminum or the molten aluminum(molten aluminum alloy), through the holding furnace and the launder get into four-wheel type continuous casting machine, continuous cast into 2450mm2 section trapezoid type aluminum ingot. The aluminum ingot is sent into automatic shearer by active pulling, and cut the scrap ingot, (after straightening 4. Main technical parameter4.1,: 9.5mm ,12mm,15mm Produced rod dia. 9.5mm ,12mm,15mm4.2,: 5.278/(9.5mm) Max. theoretic production capacity 5.278t/h (9.5mm aluminum or aluminum alloy rod)4.3,: 46×7.8×5.1 m() Main equipment dimension 46×7.8×5.1m (excludes furnace and cooling circulation system)4.4,: 70t Main equipment weight 70t4.5,: 770kw Total power 770kw
We, Deyang Dongfang Zhuoyue Electrotechnical Equipment Co., Ltd are located in Deyang of China, the major technology and equipment manufacturing base. Now, our manufacturing factory building covers an area of more than 10, 000 square meters. We have more than 100 sets of large and medium-sized processing and manufacturing equipment, and a well-trained design, marketing, managing, machinery processing and equipping team composed of nearly 200 people.
We can manufacture various of complete plant(the latest model in domestic market), such as, Aluminium&Alloy Rod Continuous Casting And Rolling Line, Copper Rod Continuous Casting and Rolling Line, Tubular Stranding Machine, Rigid Frame Stranding Machine, Continuous Lead Extruding Line, Straight-line Aluminium &Alloy Rod Breakdown Machine, Straight-line Copper Rod Breakdown Machine, etc.
We have strong production ability and excellent sales team, we sell our products to our user directly, also, we always sell our products by some trading company or middle trader. We exported so many products to other countries such as Kazakhstan, Indonesia, India, Thailand, Korea, Ukraine, Mexico, Brazzil, Vietnam, Argentina, Kenya and so on.
We would like to provide the high-quality products and the good service, meanwhile, we will quote you the lowest market price.
We will be together with all the staff and workers, wholeheartedly offer our service, wait for your presence and stride forward with you hand in hand towards a brighter future.
