| Prod Model: |
TM-60 |
| Global Warranty: |
24months |
| Servo Motor Control: |
Touch Screen |
| Power: |
Hydraulic |
Product Description
Double-head Pipe End Shaping Machine with Shrinking Stroke of 100mm
Detailed Product Description
Hydraulic NC Control Pipe-end Shaping Machine (Single-Head).
Especially used for pipe expand, reduce, forming etc.,
Features
1: Suitable for processing various metal pipe material in different shape;
2: The machine parts under QC inspection in order to enable the machine in good quality and performance;
3: Equipped with emergency stop switch, both manual and automatic operations are available.
|
TYPE |
TM-60 |
|
Max processing capability (O. D. x Wall) |
φ 60mm× 2.5mm |
|
Max. processing length |
150mm |
|
Motor power |
5.5KW |
|
Oil pressure |
12 Mpa |
|
Working speed |
100mm in 4-6/s |
|
Size |
2600mm x 600mm x 1400mm |
|
Weight |
1250KG |
Established in 1995 and lies by National highway No. 204, Zhangjiagang City Huashun Machinery Manufacturing Co., Ltd. is one of leading manufacturer and exporter about metal pipe material processing machinery with an area of 19, 000 square meter, having passed the authentication of ISO 9001: 2000 Quality Management System and gained a good reputation among our customers.
Our company has strong R&D team as well as the production and inspection equipments of high precision. with more than 10 years history, Huashun keeps on improving products and successfully developing full series of metal pipe material processing machines, such as SB series pipe bending machine, MC series circular cold saw cutting machine, TM series pipe end shaping machine, EF series chamfering machine, SG series saw blade teeth-making grinding machine, SX series riveting machine etc., Our products are widely used in vehicles, motorcycle, bicycle, children bicycle, steel furniture, air conditioner pipe system, petrochemical industry, bathroom equipments, shipbuilding, boiler, pipe manufacture industry. And the machines are good solution for various pipe cutting, bending, shrink/enlarge pipe end connection.
We abides by "Quality first, customer highest, sincerity base"management theory and strive to create the world first-class brand. We honestly hope to establish relationship with you in future!
