Product Description
Metal belt Brushing machine /metal belt polisher/metal belt brusher / metal belt grinder
This model of machine is mainly used for stainless steel or aluminum sheet surface hair line (HL) or SB brushing finishing with 4 scrotch-brite rollers of diameter 300mm. Brushing or finishing polishing the metal sheet. Can also used as a high stock removal method for special metals (e. G. Stainless steel, titanium, and nickel alloys).
Main features:
Machine frame made by steel casting
Sheet feeding through will rollers, feed speed changes
The 4scrotch-brite rollers(wheels) work separately or together
Ideal feeding table design
Feeding table height keep the same,
Main motors fixed inside the machine body
The rollers lift or lower with hand wheels
Low maintenance
Main technical data:
Machine model MS4R-127
Working work piece Thickness 0.5-50mm
Length More than 400mm
Width 40-1270mm mm
Feed speed 6-30m/min
Motor power
(KW) Main motors 7.5kwX4
Feed-through motor 3.0
Cleaning brush motor 0.37
Air Consumption volume 0.9m3/min
Working pressure 0.55MPa
Dust Exactor Wind volume 6500 m3/h
Pressure 2300PA
Wind speed 25-30m/s
Machine size the main machine 2050x1650x2620mm
Control cabinet 400x1140x850mm
Net weight About 4, 400kgs
Machine model MS4R-160
Work piece Thickness About 0.5-30mm
Length More than 400mm
Width 40-1580mm mm
Max. Feed speed 15 m/min or 20m/min or 30 m/min
Motor power
(KW) Main motors 12kwX4
Feed-through motor 3.0
Cleaning brush motor 0.37
Air Consumption volume 0.9m3/min
Working pressure 0.55MPa
Dust Exactor Wind volume 7500 m3/h
Pressure 2500PA
Wind speed 25-30m/s
Machine size the main machine
Control cabinet
Net weight About 4, 800kgs
Acter Enterprises Co., Ltd. located in the Coastal city of Qingdao, supplies many kinds of machinery rang from surface treatment protective machines to woodworking machine, Our main product have been exported to all over the world, such as the U. S. A, Vietnam, Thailand, Syria, Iran, Singapore., Turkey, Romanian, Slovakia, Russian. Our products catalogues: Our wide range of products includes grinding, polishing and brushing units for metals. Mainly include metal sheet surfaces grinding polishing machine(No. 3, No. 4, HL, SB), wide belt grinders (dry/wet/oil operate), the material and machine for surfaces laminating is adhesive protective film, PE protective film and film laminator laminating machine., film coating machine, film applicators; Woodworking machine included: Wood brushing machine, floor sanding machine, WPC brushing machine, wood polishing machine
We understand clearly that customers not only order the complete machinery, but also needs the good after-sales services. with years of unremitting technological innovation and marketing efforts, we have gained a positive standing in the markets and some of our news clients know our company and products through recommendations given by our current machine users.
Besides, we are offering agency services by the courtesy of our certification and qualifications.
We sincerely welcome all clients to contact us for details and we can customize the machine as your requirement.
Technological innovation
Our company's unremitting technological innovation enable us to product machine to your standards and to meet the customs' requirement. We also utilize CNC equipment to make complex and high tolerance products
Machining
Our combined facilities enable us to machine products to your standards. We utilize CNC equipment to make complex and high tolerance products
Assembling
We do many types of assembling. This will allow you to purchase a finished product rather than just a component.
Quality Control
Our inspectors test the products we sell for durability, accuracy and performance. We sell only quality products that meet or exceed your standards.
Management
The strict and order management guarantee the development of our company. The strict quality control and technological innovation enable us to make machine to you standards.
