| Prod Model: |
WF-JF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Item: |
OEM Steel Mental Iron Casting for Carbon Steel |
| Raw Material: |
Carbon Steel, Stainless Steel |
| Factory: |
Over 15 Years' Experience |
| Technics: |
Sand Casting+CNC Machining |
| Size: |
Cn150X150mm |
| Weight: |
0.5-50 Kgs |
| Preision Casting: |
Lost Wax Casting |
| Casting: |
Die Casting Sand Casting |
| OEM And ODM: |
100% |
| Export Markets: |
Global |
| Type: |
Chemical Hardening Sand |
Product Description
OEM Steel Mental Iron Casting for Carbon Steel Casting
Casting parts,sand casting parts,precision casting parts,stainless steel casting parts,steelcasting parts,steel casting ,stainless steel casting,carbon steel casting,
casting,metal casting
OEM Steel Mental Iron Casting for Carbon Steel Casting
production details:
1.Material: GGG40.
2.Size:CN150X150mm.
3.Weight:3.4kg.
4.Technological process: Sand casting+CNC Machining.
5.Inspection: mechanical properties, leaking free test conducted by in-house or third party
6.Use: Submersible pump body .
production capacity:
1.Casting classification:Sand casting;Precision casting;Vacuum process casting etc.
2.gray iron, ductile iron, stainless steel ,carbon steel,alloy steel, etc.
3. Adoption standard: BS,DIN,ASTM GB etc.
4. Weight range:0.5~5000kg.
5. Producing capacity : 2,000 tons per month .
6. Main application: Metallurgy;Machinery;Plastics;Rubber;Pharmaceutical;Textiles; Mining; Paper-making; Packaging.
7. Main equipments: Furnaces;heat treatment furnaces;direct-reading spectrometer;shot -blasting equipments, etc.
8. Surface treatment: polishing,plating,shot blasting,heat treatment ,etc
9. Inspection and test: Foundry in home,third part inspection,Material report,UT, MT, RT, and PT,etc..
10. Packing and shipping : Stand export packing;20day make modul & sample;delivery time against your quantity.
11. Casting service: your logo, character, trade name, number etc can be casted on the surface clearly.
OEM Steel Mental Iron Casting for Carbon Steel Casting
1.Ductile Iron Castings:
molding process: Resin sand/Green Sand
Material: EN-GJS-400-15/EN-GJS-500-7/EN-GJS-600-3/EN-GJS-700-2
Molding: Hand molding/Molding machine Z145/146/148/Molding line.
Possible Heat Treatment: Annealing
Industry involved: Municipal Construction / Fluid
/Automotive
Part unit weight range: 0. 5kg-2000kgs
Max/Min wall thickness requirements: 4mm-250mm
Manufacturer Certification: ISO9001(2000)/ TS16949
OEM Steel Mental Iron Casting for Carbon Steel Casting
2. Grey iron castings:
1) molding process: Green sand/Resin sand
2) Material: EN-GJL-150/DIN 1691 GG-15,EN-GJL-200/DIN 1691-GG20,EN-GJL-250/DIN1691-GG25
,EN-GJL-300/DIN1691-GG30
3) Molding: Hand molding/ Molding machine Z145/146/148/Molding line.
4) Industry involved: Municipal industry/Construction Fluid industry/Automotive industry
5) Part unit weight range: 0.5kg-2000kgs
6) Max/Min wall thickness requirements: 4mm
7) Manufacturer Certification: ISO9001(2000)/ TS16949
OEM Steel Mental Iron Casting for Carbon Steel Casting
OUR MACHINING PROCESS :
Occupies an area more than 6,000 square meters
More than 40pcs big CNC lathes Ø500 - Ø1200
Machining center 1400 x 825 x 1000mm 4 axis
Can provide services: turning; milling; grinding; drilling; inserting; broaching; boring; polishing
Surface preparation: passivation; polishing; plating; coating; painting; zinc phosphate; dacrotized / dacromet technology
OEM Customized Metal Iron Casting Parts with Drawings or Samples
Specifications
Ductile iron Sand Casting Water pump bodys
1.strict QC & timely delivery
2.Standard:BS,DIN,ASTM
3.good at custom
4.OEM
OEM Steel Mental Iron Casting for Carbon Steel Casting
| Material | 1.Sand casting&Gravity casting&Low pressure die casting:
A356/A319/A413/ZL101/ZL102/ZL104/ZL107/LM6//LM/20/LM25/ENAC-42100/ENAC-42200/EN AC-43000/ENAC-43200/EN AC-46000/EN AC-46200
2.High pressure die casting:
A380/A390/A360/ADC10/ADC12/ENAC-43400/ENAC-44300/ENAC-44400/ENAC-46000/ENAC-46100/ENAC-46200/
3. CNC machining casting: 6061-T6/6063-T6 |
| Processing | Sand casting, Gravity casting, high pressure die casting, low pressure die casting and CNC Machining casting. |
| Design | As per the customer's drawings |
| Equipment of Casting | 1.High pressure die casting machining: 125T/180T/250T/ 280T/500T/800T/1250T 2.Gravity casting machine: 5 production lines
3.Low pressure die casting machining: 1 production line
4.Sand casting machine: 6 production lines
5.Degassing equipment and opportunities to refine the material
6.Machining: 3Sets CNC Machine;3 sets Milling machine; 3 sets Turning machining; 10 sets drill and tap machine |
| Testing Facility | Spectrometer, tensile test machine, hardness test machine, CMM dimension report |
| Certificate | ISO9001:2008/SGS |
| Standard | ASTM, DIN,JIS, EN, ISO, GB standards |
| Software | Pro/E,UG, Solidworks, Auto CAD, PDF |
| Precision Machining | CNC turning, milling, drilling, grinding, cutting, reaming and threading |
| Finished | Polishing, sand blasting, heat treatment, painting, powder coating, anodizing, electroplating, Chrome plating, mirror polishing. |
| Service | OEM service available,produce according to customer's drawings |
| Products & Application Scope | All kinds of aluminum casting: include automotive parts, railroad parts, medical parts, marine parts, lighting parts, pump body, valve parts, architectural parts and furniture parts so on |
| Advantages | 1. Lutz works with over 8 years in Aluminum casting for Japanese and German market;
2. Lutz have four casting types producing lines;
3. Near Sea Port and Air Port;
4. Passed ISO9001:2008/SGS ;
5. OEM service according to customers'drawings;
6. From Casting to finished surface, owned casting, polishing and plating workshops.Wcan offer good quality and strict delivery time;
7. With samples and order: We can offer dimension report,Chemical composition and Mechanical properties;
8. Control material with spectral and thermal analysis equipment (density and processing);
9. Spectral analysis of raw-material and liquid melt, batch before casting. |
OEM Steel Mental Iron Casting for Carbon Steel Casting
Q: Why choose Shengao product?
A: We shengao have our own plant-- Weifang Shengao machinery Co., Ltd, therefore, we can surely promise the quality of every product and provide you comparable price.
Q: Do you provide OEM Service?
A: Yes, we provide OEM Service.
Q: Do you provide customized casting products?
A: Yes. Customers give us drawings and specifications, and we will manufact accordingly.
Q: What is your payment term?
A: We provide kinds of payment terms such as L/C, T/T, Paypal, Escrow, etc.
If there's anything I can help, please feel free to contact with me.
