| Prod Model: |
GWC76-344-688 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Precise Forming: |
High Quality |
Product Description
Our company specifies provide Roll forming machine, Roof/Wall panel machines, C/Z purlin machine, Floor decking machines, corrugated panel machine, Gutter machine, K-Span forming machine, Cable tray forming machine, Slitting machine, Decoiler, Steel tile forming machine, Door frame machine, Rack column machine, Guide rail machine, Guard rail machine, Roofing hanger machine, Ridge cape machine, Designing service, construction material, Steel Coil which is
1. Precise forming
2. High-solid forming stand guarantees the goods and uniform high quality of final productd
3. The operation automatically minimizes the tolerance of cutting length
4. The line has the advantages of the single structure, beautiful interface, steady function and convenient operation.
1. Main Parameter:
1) Material to be rolled: Q235 galvanized Steel coil
2) Thickness of the material: 0.8-1.5mm (subject to the buyer's requirement)
3) Coil width max: 1000mm
4) Inner diameter of the coil: 520mm, subject to buyer's requirement
5) Outer diameter of the coil: <=1800mm
6) Decoiler: 10T, manual expansion
7) Roll stands: 28
8) Main structure: Wall style entire steel structure
9) Driving system: Chain transmission
10) Main power: 15KW
11) Main reducer: Cycloid pin
12) Cutting: Hydraulic cutting
13) Power of hydraulic station: 3KW
14) Material of blade: Cr12, heat treated HRC58-62
15) Measure: Encoder
16) Controller: PLC Mitsubishi Touch screen Panasonic Invertor: Panansonic
17) Forming speed: About 10m/min
18) Dimension: Abt. 16m*1.7m*1.5m
19) Weight: Abt. 18mt
2. Process:
Manual decoiler__guiding__roll forming__hydraulic cutting__run out table
Guangcai company is a group company which concentrates on roll forming equipment manufacturing, roll formed material processing, sales and service.
Our company was founded in 1995. After 15-year's development, group company is possessed of four branch companies currently: Wuxi Guangcai Machinery Manufacture Co., Ltd, Wuxi Suyun Floor Steel Panel Co., Ltd, Shanghai Suyun Constructional Steel Product Co., Ltd, Suzhou Guangcai Constructional Steel Products Co., Ltd.
Company is capable of manufacturing more than 20 series of roll forming equipments, such as color steel panel roll forming machine, glazed steel tile roll forming machine, floor deck roll forming machine, multi-functional complex panel roll forming machine, C, Z purline roll forming machine, integral carriage panel roll forming machine, steel silo roll forming machine, guard rail roll forming machine, big span forming machine, adjustable special profiled material roll forming machine, environment-protection material roll forming machine, cable tray roll forming machine. Our products have been exported to more than thirty countries and regions. At the same time, company made full use of technique advantages, established production base of roll formed panels in Wuxi and Shanghai. In market competition with numerous rivals, our products gained full acceptance and favor from a great deal of customers. For seizing development opportunities, our company is equipped with varied, efficient roll forming production lines, such as 21 types of floor deck roll forming machines, 45 types of color steel roll forming machines, and 5 types of universal adjustable special profiled panel forming machines, which can roll-form more complicated and demanding profiled panels.
Our company has a High-quality troop with great design and manufacture talent, including more than thirty senior and junior technicians, total staff more than four hundred.
Company mission: Honest-oriented, Quality first, Credibility first, After-sales service first. We will bring the best products and service to customer all over the world.
