Prod Model: |
SC12, SC14, SC16, SC18, SC20, SC25, VSC12, VSC14, |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Mould Size: |
9", 12", 14", 16", 18", 20" |
Casting: |
Centrifugal Casting |
Product Description
1/. Semi-automatic centrifugal casting machine from China.
Models: SC12, Sc14, Sc14, Sc18, SC20, SC25
Application:
It is used to produce casted buckles and accessories for the leather industry and garment industry, promotion gifts, medal, and figurines etc. From zinc alloy or tin alloy.
Features:
1. Digital speed display.
2. Digital timer for centrifugal time setting.
3. Cover Automatic open / close design, effectively saving time and labor.
4. Adopt variable frequency driver for speed regulation in range 50-1400 RPM for more processing Options
5. Safety protection of the centrifugation area
6. Electronic emergency brake system
7. Fan for mould cooling.
8. Easy operated and maintained
2/. Semi-auto vacuum centrifugal casting machine:
Models: VSC12, VSc14, VSc14, VSc18, VSC20, VSC25
With an option vacuum pump, semi-auto vacuum centrifugal casting machine is used to produce precision casted buckles and accessories for the leather industry and garment industry, imitation jewelry, promotion gifts, medal, and figurines etc from zinc alloy or tin-lead alloy.
Features:
1. Efficient vacuum pump, centrifugal casting cycle shorted, cooling faster, rubber mold working life prolonged.
2. Digital speed display, digital counter.
3. Digital timer for centrifugal time setting.
4. Cover Automatic open / close design, effectively saving time and labor.
5. Adopt variable frequency driver for speed regulation in range 50-1400 RPM for more processing options.
6. Safety protection of the centrifugation area.
7. Electronic and pneumatic double emergency brake systey.
8. Easy operated and maintained.
Semi-auto spin casting machine | SC12 | SC14 | SC16 | SC18 | SC20 | SC25 |
Mold dia. max | 12" | 14" | 16" | 18" | 20" | 25" |
Mold thick | 0-120mm |
Pressure | 0-7KG |
Power | 0.75Kw | 1.5Kw | 1.5Kw | 1.5Kw | 2.25Kw | 3.0Kw |
Speed | 50-1400rpm |
Semi-auto vacuum spin casting machine | VSC12 | VSC14 | VSC16 | VSC18 | VSC20 | VSC24 | VSC25 |
Mould dia. max | 12" | 14" | 16" | 18" | 20" | 24" | 25" |
Mould Thick | 0-120mm |
Clamping Pressure | 0-0.7Mpa |
Centrifugal | Power | 1.5kw | 1.5kw | 1.5kw | 1.5kw | 2.25kw | 3.0Kw | 3.0kw |
Speed | 50-1400rpm |
Vacuum pump | Pressure | 0.07Mpa |
Power | 0.75kw | 0.75kw | 0.75kw | 0.75kw | 1.5kw | 1.5kw | 1.5kw |
