Single Cylinder DC40 Hydraulic Ironworker Punching

Single Cylinder DC40 Hydraulic Ironworker Punching
Price: Negotiable/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: L/C,T/T
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color And Voltage: According to Customer's Request
Machine Type: Hydraulic Punching Machine
Certificate: ISO&CE
Automatic Grade: Non-Auto
Power: Hydraulic Punching Machine
Processed Material: Carbon Steel, Stainless Steel, Alloy
Raw Material: Cast Iron, Steel
Model: DC-40, DC-60, DC-90, DC-120, DC-160, DC-180

Product Description

Hydraulic Punching Machine:

1. Laser position system
2. Whole forged cylinder avoid leaking
3. Temperature cooling system
4. Passed CE, ISO, SGS, CQC

Hydraulic transmission, low noise, safe and reliable. Can punch plate, angle, channel and all kinds of steel, can bend the plate below length 300mm. Model structure for the unique design of a variety of molds can be quickly replaced.

This punching steel Worker is an ideal multi-function equipment for cutting angle, round, flat bar, punching, joist, as well as notching, channel, equipped with related stop device for cutting.

Welecome to contact with us for details!
Model: Unit DC-40 DC-60 DC-90
Working  pressure  kn 400 600 900
MAX.   punching  thickness mm 12 16 20
Max.   capacities  mm 25*12 25*16 30*20
Tensile  strength  of  sheet  metal N/mm2 ≤ 450 ≤ 450 ≤ 450
Stroke  of  ram mm 80 80 80
Stroke  times min 8 8 8
Depth  of  throat mm 300 380 450
Main  motor kw 4 4 5.5
Length  of  machine  tool mm 1100 1180 1420
Width  of  machine  tool mm 770 770 790
Height  of  machine  tool mm 1770 1760 1990
Weight  of  machine  tool kg 775 970 1600

Model:   DC-120 DC-160 DC-180
Working  pressure  kn 1200 1600 1800
MAX.   punching  thickness mm 25 30 30
Max.   capacities  mm 35*25 38*30 45*30
Tensile  strength  of  sheet  metal N/mm2 ≤ 450 ≤ 450 ≤ 450
Stroke  of  ram mm 80 80 80
Stroke  times min 8 8 8
Depth  of  throat mm 500 600 900
Main  motor kw 7.5 11 11
Length  of  machine  tool mm 1750 2050 2110
Width  of  machine  tool mm 970 1050 1050
Height  of  machine  tool mm 2000 2300 2300
Weight  of  machine  tool kg 2950 4800 5300

We are a hi-tech enterprise in Jingjiang. We are mainly specialized in the research and development of kinds of metal workers.

Products Include: Iron worker, hydraulic iron worker, electro-hydraulic synchronized CNC press brake, hydraulic punching, hydraulic press brake, bending machine, hydraulic shear, hydraulic shearing machine, hydraulic cutting machine, hydraulic swing beam shear, hydraulic guillotine shearing machine, autofeed hydraulic shear, hydraulic shear with pneumatic support device

Our ironworers, which have been sent to Australia, are all equipped with ATOS pump valve of Italy, and Electric's appliances. Before the installation, we will provide two solutions for customers' choices, respectively adopted different configurations of world brand products and Chinese famous brand products. We make sure the quality, and satisfy the clients with comprehensive after-sales service.

Jiangsu Puxin Machinery Manufacturing Co. Ltd is the production of various types of forging press machines and equipment professional firm, the company passed the ISO9001: 2000 quality system certificatian and export of electromechanical products through a national license certification and CE certification.

Company has first-class professional and technical personnel, strong technical skills, complete testing means. Our long-term accumulated experience and lessons to broad areas of advanced technology to constantly adjust product structure, to market the most sophisticated forging machinery. Selling products, a large number of exported to Europe, the Middle East and Southeast Asia, has long been Chinese and foreign custmers alike.

Each of the company manufacturing parts for each machine in a safe, functional, maintenance, and performance in line with the highest quality requirements, its design based on use of human and machine control based on the quality and reliability is our top priority. The company will adhere to the people-oriented, science as a precursor to new business ideas, science service, customers return to the company, and our aim is to"honesty, quality first. "with yhe company's products, you will have the strength and the future!
