| Prod Model: |
CDLF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Method: |
Combined Treatment |
| Usage: |
Home |
Product Description
OverviewNon self-priming type vertical multistage centrifugal pump, the motor is directly connected with the pump through shaft couplings, impeller guide vane is made of stamping stainless steel plate or precision casting stainless steel, smooth surface, hydraulic flow loss is small, and easily for cleaning, is very favorable for conveying pure medium. Pump inlet and outlet in a straight line(can be equipped with IEC or NEMA motor).
Operating ConditionsThin, clean, non inflammable and explosive liquid not containing solids or fiber.
The liquid temperature: Normal temperature type - 15 º C to 70 º C hot water type to + 120 º C
Environmental temperature: Highest + 40 º C
Height: Highest 1000m
MotorMotor is fully enclosed, air-cooled type 2 pole standard motors.
Protection grade: IP55
Insulation grade: F
Standard voltage: 1pH 220-230/240V
3pH 200-220/346-380V
3pH 220-240/380-415V
3pH 380-415V
Typical ApplicationWater supply: Water filtration and conveying, waterworks water supply, pipe pressurization, high-rise building pressurization.
Industrial pressurization: Process water system, cleaning system, high pressure flushing system, fire control system.
Industrial liquid transportation: Cooling and air conditioning system, the boiler feed water and condensation system, machine tool accessory, acid and alkali.
Water treatment: Ultrafiltration system, reverse osmosis system, distillation system, separator.
Irrigation: Farm irrigation, sprinkler, drip.
Model |
CDLF2 |
CDLF4 |
CDLF8 |
CDLF16 |
CDLF32 |
CDLF42 |
Rated flow[m3/h] |
2 |
4 |
8 |
16 |
32 |
42 |
Flow range[m3/h] |
1-3.5 |
1.5-8 |
5-12 |
8-22 |
16-40 |
25-55 |
Max. Pressure[bar] |
23 |
22 |
21 |
22 |
26 |
30 |
Motor power[Kw] |
0.37-3 |
0.37-4 |
0.75-7.5 |
2.2-15 |
1.5-30 |
3-45 |
Head range[m] |
15-195 |
16-176 |
18-180 |
22-189 |
13-196 |
16-259 |
|
Temperature range[] |
-15 -+120 |
Max. Efficiency[%] |
46 |
59 |
64 |
71 |
76 |
78 |
Shanghai SUOTO Pump Industrial Co., Ltd. is a ISO9001-2008 listed company, which is located in Shanghai, and has production bases in Zhejiang, Hunan. It is a famouse diversified enterprise integrating R&D, production, sales and service of various kinds of pumps. Main products are Centrifugal pumps, Chemical pumps, Sewage pumps, Oil pumps, Vacuum pumps, Diesel pumps, Water supply system, etc. We have obtained import and export license, and own an independent foreign trade department with a good professional team, providing superb and efficient service for foreign merchants. Now 70% of our pumps are exported to over 40 countries in South East Asia, Middle East, Africa, Europe...
The company introduced the world's advanced fluid flow analysis, three-dimensional CAD, CAM, FMS and other R&D software system, and implementation of ERP management. It boasts a leading pump test center, laser forming device, coordinate measuring machine, 12M vertical CNC lathes and other total more than 200 units / sets of advanced production and testing equipment. Products cover construction, municipal, power, petroleum, chemical, mining and other dozens of categories, the annual production capacity of 10 million units / sets. The company has the domestic first-class production equipment and sophisticated detection equipment, every step of the product is under rigorous testing to ensure the highest standards at the factory.
With the steady development, our company has established a perfect sales and service system, providing our clients with professional technical support and services. Company currently has: Hangzhou Sibao Sewage Treatment Plant, the water cycle works in Guangzhou New Baiyun Airport, Hebei Datang Power Plant, Bao Steel and the UAE BK Gulf LLC, Vietnam Oil and Gas Group Petrovietnam, Myanmar Ticyit Coal -Burning Firepower Plant, Pakistan Darawat Dam project, and other large numbers of domestic and foreign model works.
