| Prod Model: |
KLS25-220-530 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cold Roll Forming Machine: |
Roofing Forming Machine |
| Dimension: |
1800*1100*1000mm |
| Weight: |
600kgs |
| Motor Power: |
1.5kw |
| Power For Hydraulic Forming Cutter: |
0.75kw |
| Forming Steps: |
6steps |
| Height Of Roofing: |
25mm |
| Effective Width: |
220-530mm |
| Material Width: |
290-600mm |
| Material Thickness: |
0.5-0.8mm |
Product Description
KLS25-220-530 Mini Standing Roofing Panel Forming Machine, Panel Forming Machine and Metal Roof Machine:
Main Technic Data:
Type: KLS25-220-530;
Size: 1800*1100*1000mm(L*W*H);
Weight: 600KGS;
Motor Power: 1.5KW;
Effective Width: 220mm, 530mm;
Material Width: 290mm, 600mm;
Material Thickness: 0.5-0.8mm;
Materail: Galvanized sheet, Al-Mg-Mn sheet, Colored prepainted sheet.
Usage: Making standing seam roofing panels for buildings.
|
Size |
1800*1100*1000mm |
|
Weight |
600KGS |
|
Motor Power |
1.5KW |
|
Power for hydraulic forming cutter |
0.75kw |
|
Voltage |
380V/50HZ/3PH |
|
Forming Steps |
6steps |
|
Processing Speed |
8-12m/min |
|
Voltage |
380V/50HZ/3PH |
|
Material Thickness |
0.5-0.8mm |
|
Standing Height of Roofing |
25mm |
|
Thickness for common use and testing machine |
0.6mm, 0.7mm (material: PPGI, GI, Aluminum) |
|
Effective Width of Roofing |
220-530mm |
|
|
Material Width |
290mm-600mm |
|
Material of principal axis |
high grade 45# forged steel |
|
Material of roller |
45#steel with hard chrome plating |
|
Material of blade |
Cr12 mould steel with quenched treatment 60-62°C |
|
Material for frame of machine |
Fine welded structural steel, and one side of frame can be moved |
|
Sprocket wheel |
45 steel high-frequencies quench |
|
Material for producing roofing |
normal Colored coated ,Steel, galvanized steel, and Aluminum sheets |
|
Usage |
Producing standing seam roofing panels |
Established in 2004, Xiamen Xinhonghua Machinery Co., Ltd which is load in nice island city of Xiamen is specialized in manufacturing roll forming machines with hydraulic systems and PLC computer controlling systems. Our company has advanced technologies and great experience in the R&D, manufacture, installation, testing and training.
Our company can supply a wide range of Al-Mg-Mn panel forming machines, standing seam roofing machines, C/Z shaped Auto full adjustment purline machines, tapered-shaped standing seam roofing machines, colored roof panel machines, glazed tile machines, shaft forming machines, rolling door machines, flattening machine with slitting and cutting device, floor decking machines, highway guardrail machines, auto adjustment curving machine and hydraulic bending machines.
We enjoy a good reputation with the enterprise spirit of "Innovation chases the development; Management earns benefit". We insist on the service philosophy of "Satisfying our customers' needs".
Our products sell well at home, and are exported to clients in the Philippines, Indonesia, India, Malaysia, Ameria, Dubai, Singapore, Brazil, Turkey, Canada, Africa, Tailand, Columbia, the Middle East and other countries and regions.
