Steady Working Condition Iron Melting Furnace (JL-KGPS)

Name: Steady Working Condition Iron Melting Furnace (JL-KGPS)
Brand: china-castingforging.com
SKU: 740237705
Availability: InStock
Rating: 5 (23 reviews)

Price:	US $ 1000-100000/Set
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Set
Pay Type:	L/C,T/T,D/P,Paypal,Western Union

Contact Supplier

Dongguan Jinlai Electromechanical Device Co., Ltd.

Showroom Product Company Profile

Prod Model:	JL-KGPS
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certificate:	ISO9001:2008,CE,SGS
Feature:	Energy Saving,High Efficiency
Package:	Plywood Case
Warranty:	1 Year
After-Sales Service Provided:	Engineers Available to Service Machinery Overseas

Product Description

Steady Working Condition Iron Melting Furnace

1. Overview
Medium Frequency Induction Furnace is the device converting three phase power current into single-phase intermediate frequency current and enabling metal to produce eddy current loss through the electromagnetic field induction to achieve heating and melting. Mainly be used in the material of ferrous and non-ferrous metal casting, melting and heating treatment industry, such as iron, steel, brass, cooper, zinc, tin and so on. As well as heating treatment prior to forging, sintering and tube-bending forming in casting and melting industries.

2. Performance Characteristics:
1. Zero-voltage scanning soft, available for start or stop at any time under any state without impact on power supply;

2. Speedy melting, low production cost, low pollution, conforming to environmental protection requirement;

3. Melting directly from low temperature, available for fully emptying of solution, easy change of category of melting material;

4. Flexibly adjustable power, easy and continuous smooth adjustment, easily controllable temperature, low oxidization loss, uniform metal content;

5. Furnace shell with cast aluminum ally or steel shell construction, small footprint, easy overturn body, available for selection of electric, manual, hydraulic or other overturn mode as needed;

6. Contravariant automatic regulation circuit available for matching of load impendence automatically, maintaining good operation without regulation or compensation of capacitance; Power supply with fault diagnosis facilitating service.

Furnace Capacity	Rating Power	Input Voltage	Input Phase	Input Current	Assorted Transformer	Output Voltage	Output Frequency	Melting Time	Volume	Weight
10-50KG	50KW	380V	3	80A	60KVA	750V	2.5KHZ	20-60Min	1.2 m³	350KG
100KG	100KW	380V	3	160A	120KVA	750V	1KHZ	20-60Min	6 m³	1500KG
150KG	100KW	380V	3	160A	120KVA	750V	1KHZ	30-70Min	6.5m³	1600KG
200KG	120KW	380V	3	192A	150KVA	750V	1KHZ	30-70Min	7.5m³	1700KG
300KG	130KW	380V	3	208A	150KVA	750V	1KHZ	30-70Min	8.5m³	1800KG
500KG	250KW	380V	3	400A	315KVA	750V	1KHZ	30-70Min	9.5m³	2300KG
600KG	350KW	380V	3	560A	400KVA	750V	1KHZ	40-80Min	11m³	2500KG
750KG	450KW	380V	3	720A	500KVA	750V	1KHZ	40-80Min	12m³	3800KG
1000KG	600KW	380V 380V-2	3/6	960A 480A	600KVA 800KVA	750V 1300V	0.8KHZ	50-90Min	13m³	4500KG
1250KG	800KW	380V 380V-2	3/6	1280A 640A	800KVA 1250KVA	750V 1300V	0.8KHZ	50-90Min	14m³	5000KG
1500KG	1000KW	380V 380V-2	3/6	1600A 800A	1250KVA 1500KVA	750V 1300V	0.8KHZ	50-90Min	15m³	5500KG
2000KG	1250KW	660V 380V-2	3/6	1120A 1000A	1500KVA 1800KVA	1300V	1300V	50-90Min	17m³	6000KG
3000KG	1500KW	660V 380V-2	3/6	1350A 1200A	1800KVA 2000KVA	1300V	1300V	60-100Min	20m³	7000KG
5000KG	2500KW	1000V 660V-2	3/6	2000A 1120A	3000KVA 3500KVA	1300V	1300V	60-100Min	23m³	8500KG

Dongguan Jinlai Electromechanical Device Factory, founded in 1996, which is engaged in R&D, production and sale of solid Induction heating machine professionally. Several senior experts of induction heating equipment gathered here, who initiate the induction heating machines with environmental protection and highly effective energy conservation, positively and diligently.

Now there are series of products range from 3KW to 600KW, including the ultra-high/high/ super-audio/medium frequency induction heater, KGPS Parallel IF Power supply, IGBT energy saving IF power supply, 12 pulse IF furnace and special equipments (e. g. High-frequency quenching machine, Medium-frequency induction melting furnace, Ultrasonic -frequency annealing machine, Induction forging furnace, Brazing machine, Plastic welding machine, Branch divider/Bicycle fittings special -purpose welding machine, Railway river furnace, etc). These products are widely applied in the heating of hardware, metal (steel, iron, copper, aluminum) processing, plastic, deeply heating shaping, brazing, hardening, melting, annealing, hot cooperation and so on.

It was certified to ISO9001: 2008 quality system and CE certification. Advocating quality management conception of "producing products with zero defect", the quality has been guaranteed. The company has been sated up and perfected the marketing network and after-sales system. Our products are widely exported to Russia, USA, Italy, Romania, Netherlands, Finland, Turkey, Ukraine, Argentina, Brazil, India, Pakistan, Malaysia, Indonesia, Thailand, Vietnam and other countries or region. Most of products gain good reputation from customers.

Our conception is "human-oriented, service the society with innovation". "the quality and prestige are the fist" is our mission. The principle is "communal development, mutual benefit, we are looking forward to cooperate with you to create a bright future!
