| Prod Model: |
AC20160229102 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Casting Material: |
Aluminium Alloy Zl101, A356, ADC12, Alsi7mg |
| Specification: |
Customized Size |
| Manufacturing Process: |
Die Casting, Option Gravity Casting, Low Pressure |
| Casting Tolerance: |
CT5-7 for Aluminum Casting |
| Machining Process: |
CNC Machining/ Lathing/ Milling/ Turning/ Boring/ |
| Surface Treatment: |
Anodize, Painting |
| Rough Surface Roughness: |
Ra3.2-25 |
| Package: |
Multiplayer Wood Box/Pallet, with Big Plastic Bag |
| Lead Time: |
45 Days |
| Service: |
OEM/ODM for Sheet Metal Work and Aluminum Casting |
| Material: |
Aluminum |
| Surface Preparation: |
Anodize, Painting |
| Certification: |
Ts16949 |
Product Description
General Products
Application/Service Area |
Metal Parts Solution for Vehicle, Agriculture machine, Construction Machine,
transportation equipment, Valve and Pump system, Agriculture machine
metal Parts, engine bracket, truck chassis bracket, gear box , gear housing ,
gear cover, shaft, spline shaft , pulley, flange, connection pipe, pipe,
hydraulic valve, valve housing ,Fitting , flange, wheel, fly wheel,
oil pump housing, starter housing, coolant pump housing, transmission
shaft , transmission gear, sprocket, chains etc.
|
Main blank Process for Aluminum Casting |
Die Casting, Permanent Molding /Gravity Casting, Low Pressure Casting,
High Pressure Casting/Sand Casting, Extrusion Casting etc. |
Blanks Tolerance -Casting Tolerance |
CT4-6 for Permanent Molding, Die Casting, CT 9-11 for Sand Casting |
Applicable Material for casting |
A356.0/ZL101,GAlSi7Mg (3.2371.61)/AlSi7Mg/, A-S7G, Al Si Alloy, Al Cu Alloy ZL201 Al Mg Alloy ZL301,ZL302,
Al Zn Alloy ZL401Zn Alloy Zamak 3, Zamak 5, Zamak 7, Zamak 2
Or according to customer requirements
|
Casting Blank Size /Dimensions |
2 mm-1500mm / 0.08inch-60inch , or according to customer requirements |
Casting Blank Weight |
Range from 0.01kg-50kg |
Applicable Machining Process |
CNC Machining/ Lathing/ Milling/ Turning/ Boring/ Drilling/ Tapping/
Broaching/Reaming /Grinding/Honing and etc.
|
Machining Tolerance |
From 0.005mm-0.01mm-0.1mm |
Machined Surface Quality |
Ra 0.8-Ra3.2 according to customer requirement |
Applicable Heat Treatment |
T5~T6 |
Applicable Finish Surface Treatment |
Shot/sand blast, polishing, Primer Painting , Powder coating, ED- Coating,
Finish Painting, Anodize (White or Black Color) |
MOQ |
For casting : 200pcs
For Machining: 50pcs |
Lead Time |
45days from the receipt date of deposit for aluminum die casting |
|
Matech Industry ltd specializes in Metal Parts Solution for Vehicle, Agriculture machine, Construction Machine, transportation equipment, Valve and Pump system.
With keeping manufacturing process design, quality planning, key manufacturing processes and final quality control in house we are mastering key competence to supply quality mechanical parts and assembly to our customers for both China and Export Market .
To satisfy different mechanical and functional requirements from our customers we are able to make a big range of metal products for our clients on base of different blanks solutions and technologies. These blanks solutions and technologies include processes of Iron Casting, Steel Casting, Stainless Steel Casting, Aluminum Casting and Forging.
During the early involvement of the customer's design process we are able to provide professional input to our customers in terms of process feasibility, cost reduction and function approach. You are welcome to contact us for technical enquiry and business cooperation.
Shanghai Matech Machinery Manufacture Corporation, branch of Matech Industry, provide high quality sanitary valve, ball valve, gate valve for food, wine, chemistry and oil industry. As a 15 years manufacture in foundry and machining business areas Matech also produce iron casting, steel casting, aluminum casting, stainless steel casting and forging parts for vehicle and agriculture machine, pump and valve, transportation system and other industrial customers all over the world.
We are focus on metallurgical technology, foundry engineering, manufacturing and assembly test to fulfill customers' high requirements and secure high reliable quality for each delivery. As a successful supplier in supplying products to both European and North American market and quality system certified manufacture we prize the honor we have gained from the customers and market on quality, delivery, service and cost control. Matech Team is always ready to listen to the customer's voice and build value to our customer's application and business. We provide early involvement on design support and review input eg. Manufacturing feasibility analysis for the specified project of our customers when this is needed by our cutomers.
Matech team members have more than twenty years experience on Valve making, foundry, mechanical engineering, manufacturing and quality assurance. MATECH promise and secure the quality for all the products delivered.
You are welcome to enquire and order products from Matech Industry, including Valve and Pump, mechanical parts made by iron casting, steel casting, stainless steel casting, aluminum casting, forging and fabrication. We produce products according to your special requirements and the standards of European or American Countries.
