| Prod Model: |
HPM-500T |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity (T): |
200 300 500 |
| Travel (mm): |
300+405 |
| Tale Size( Mm): |
900*1200 |
| Dimension(mm): |
2300*1000*2900 |
| Forging Forming Method: |
Mold Forging |
Product Description
TUV High Capacity Workshop Hydraulic Press (500T) :
HPM series hydraulic press are used for assembling, dismantling, alignment, calendaring, tension, bending and punching.
The machine supplied oil by Italy CNK and CBZ pump. It could save 60% energy compared with the traditional model. The efficiency increased to 2-3 times. It takes the advantages of small volume, high pressure, simple structure and light weight.
Features
Easy to use and powerful press for most applications
Ideal for the repair of axles, shafts, & press fit of bearings & bushings
Ram can be repositioned via crank hand wheel, slides left or right
Ram speed down 8.5mm/sec, returns 8.0mm/sec
Heavy duty welded steel fabricated frame
Strong hydraulic cylinder ensures precise pressing during operation
Fitted with pressure gauge
Safety overload valve
Hydraulic joystick control lever
Powerful TEFC motors
Heavy duty one piece table plate insert
Extra heavy duty table support with high tensile setting pins
Table can be adjusted for height using chains and Hydraulic ram
Pre-Commissioning:
1. Press is run & tested prior delivery
2. Hydraulic oil is included with machine
MODEL |
HPM-200T |
HPM-300T |
HPM-500T |
CAPACITY(KN) |
2000 |
3000 |
5000 |
PRESSURE(MPa) |
40 |
42 |
45 |
TRAVEL (mm) |
300+405 |
300+405 |
300+405 |
TALE SIZE( mm) |
500*1000 |
700*1200 |
900*1200 |
DIMENSION(mm) |
1940*900*2300 |
2100*950*2700 |
2300*1000*2900 |
|
900*800*1060 |
1100*1200*1350 |
1100*1200*1350 |
WEITHT (KG) |
2200/2400 |
3900 |
6500 |
Package: Sea worthy Package.
Payment term: 30% TT in advance, 70% TT when shipment.
Delivery time: 10-20 days.
Qingdao Prosper Machinery Co., Ltd. is one of the professional suppliers specializing in workshop Machinery and pellet machinery.
With high efficient administrative system and extensive experience, our company export complete plants and single kind of machines to over 40 countries or regions, the total value is up to USD three million every year.
Workshop Machinery: Lathe machines, radial drilling machines, milling machine, slotting machine, welding machines, power hacksaw machines, workshop presses, Hydraulic folding machine, Guillotines, etc.
Pellet Machinery: Pellet mills for poultry feed, pig feed and shrimp feed. Hammer mills, Mixers, Coolers, Sieve, etc.
Biomass pellet mill: Wood pellet mill, Biomass Pellet Mill, Sawdust Pellet Mill, wood hammer mill, pellet cooler, etc.
Welcome all friends from at home and abroad to contact us for business discussion. Our main focus is to ensure that our customers get what they need, not what we think they should need. Our team ensures that every piece of machinery gets to its destination in due time and as economically as possible.
Here is your best choice, we will supply quality products at most competitive prices and good sales service to you.
