| Prod Model: |
XZ-200B |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Eastern Asia,Western Europe |
| Working Frequency: |
0.5-20kHz |
| Duty Cycle: |
100% |
| Power Factor: |
>95% |
| Usage: |
Hot Forging |
| After-Sales Service Provided: |
Overseas Service Center Available |
| Forging Forming Method: |
Free Forging |
Product Description
1. Induction Forge Heating Machine Applications
1.1. Metal Hot Forming, Hot Forging, Hot Upsetting, Hot Pressing.
Standard components hot forging, bolts & nuts hot forging, fasteners hot forming, automobile and motorcycle parts hot pressing, metallic tools hot forming.
1.2. Heat Penetration
Bar materials hot forging, round steels forge heating, square steels hot forging, copper bar hot punching,
1.3. Metals Continues Hot Forging
Hot forging of embryo gear parts, Gears hot forging, axle shaft hot forging, connecting rod continues hot forging, Bearings precision forging
1.4. Heat distortion
Pipes Heat distortion, pipe bending, stainless pipe Heat distortion, copper rod Heat distortion, steel billets heat distortion, steel pipe heat bending
1.5. Hot Rolling Heating
Steel rod hot rolling, steel billet hot rolling, copper rod hot rolling, square steels hot rolling, bar hot rolling, hot coating
1.6. Other forge heating applications, Such as hot extrusion, hot squeezing, partial heating, heating before hot cutting, hot fitting, thermal refining
1.7. Suitable for workpiece with various shape and different diameter
1.8. Customized forging production solution
2. IGBT Induction forging system Features:
1). IGBT (Siemens) technology, high conversion efficiency
2). Energy saving 15%-30%, compared to SCR/KGPS technology
3). Much more efficient than gas-fired and coal-fired method
4). 100% start-up success rate; Power factor > 95%
5). Perfect and complete protection functions, increasing machine's reliability & stability
6). No special foundations required, Low operating cost, Easy operation
7). Modular design, ease of maintaining and repairing
3. Product Advantages
1). Energy saving, Environmental protection, Low pollution level
2). Easy operation, can be equipment with PLC controller
3). Miniature and light weight, Economic Space Occupation, Easy installation
4). Enhanced monitoring and diagnostics system— "Kechuang" device, guarantee the machine of high stability, reliability and security.
5). Strict Supplier Management System and ISO9001-2008 Quality Management System guarantee high quality of each equipment.
6). Customized services, which made machines as per customer's requirement.
4. Different shape steel bar diameter and length, heating speed, will need different power induction machine. We have done the diamter 30mm round bar forging system, so any interest or inquiries from you, welcome your letter.
| Model type | XZ-200KW |
| Input power | 200KVA |
| Input voltage | 380V±10% 50HZ/60HZ |
| Max input current | Single phase 300A |
| Oscillating frequency | 0.5-20KHZ |
| Inverted power | ≤200KVA |
| Water pressure | 0.15MPA≤water pressure≤0.3MPA |
| Product plywood Packed size | To be confirmed |
| Product plywood Packed weight | To be confirmed |
Zhengzhou Kechuang Electronic Co., Ltd, as a king induction heating machine manufacturer in China, we have the following advantages:
1. Induction heating machine power from 8KW-1000KW, with frequency range from 0.1kHz-500kHz.
2. Main circuit adopts Siemens IGBT series resonance circuit.
3. We focus on the metal parts heat treatment production line.
4. We cooperate with the Zhengzhou University.
5. We have CE, SGS certification.
Zhengzhou Kechuang Electronic Co., Ltd is Henan high& new technology enterprise, China heat treatment association membership. From the company's founding, Kechuang Electronic always takes the scientific& technological innovation as the company development driving force. Company has obtained more than ten national patents, has won many many national and provincial science&technology innovation award. Set up henan province induction heating engineering center, has developed hundreds of market welcome products. Has already passed the European Union CE certification, not only in all over China, Asia, Europe, America, Africa, Oceania, everywhere you can see kechuang products and also the engineer local service figure.
