| Prod Model: |
SB-Glazed sheet making machine |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type Of The Machine: |
Commonly Used Models or Custom-Made |
| Control System: |
Full Automatic Control System with PLC |
| Shearing System: |
Hydraulic Shearing |
| Language System: |
Both English and Chinese |
| Suitable For The Rolling Plate: |
PPGI, Galvanized Steel, Lead Plate, Stainless |
| After Service: |
One-Year Warranty, Life-Long Maintenance |
| Type: |
Finishing Machinery |
Product Description
CE certificate No: CMHB1203200958
1. Low noise, easy operate
2. Automatic cutting for length, automatic punching
3. Adopt after-cutting to ensure quality of the productions
4. Voltage: 380V /50Hz /3 phases or at buyer's
|
No. |
main parameter of roll forming machine |
|
1 |
Suitable to process |
Color steel plate |
|
2 |
Width of the plate |
1000mm |
|
3 |
Rollers |
13 rows |
|
4 |
Dimensions |
6.0*1.1*1.2m |
|
5 |
Power |
3+3kw |
|
6 |
Thickness of the plate |
0.3-0.8mm |
|
7 |
Productivity |
8-10m/min |
|
8 |
Diameter of the roller |
Φ 70mm |
|
9 |
Weight |
About 3.0T |
|
10 |
Voltage |
380V 50Hz 3phases |
|
11 |
Material of the cutting plate |
Gr12 |
